Old September 14th, 2005, 01:49 PM   #1
Wrangler

Join Date: Aug 2005
Location: Toronto, ON, Canada
Posts: 3,637
HD100 in 3D... grab your red/blue anaglyph glasses!

Last weekend I built a dual-HD100 mounting plate with a parralax/convergence adjustment. It sounds more complicated than it is. It only cost a total of $14 CDN (that's probably around $3 for those of you in the U.S.) including the scrap piece of 5.5" x 8" aluminum and the hardware.



Let me backtrack a little.
My friend John Mihn Tran, who is also a D.P., is planning to shoot a documentary about his dad who is an ex-Vietnamese army photographer, who immigrated to Canada 30 odd years ago and then started up a very successful camera store in Calgary. He is an amazing photographer, but a really amazing stereo-photographer.
So anyway, John showed me some of the incredible 3D photography his dad shoots with two Medium format Hassenblads and I was blown away.
I am also a 3D still photographer (old Kodak system) so I of course suggested that the film be shot in 3D so that the audience can get the full effect of the 3D photos.
We had two DVX100 cameras available to us, so we clamped them together and started doing some tests. The standard-def results were pretty good for landscape shots, but we needed the lenses to be closer. I bought the DVX service manual and with the help of Scott Burton, we took the door off of the left DVX to get the two closer together. Scott also modified a vacuum belt for us to "gang" the two focus rings together.





Fast forward two months...
I received two HD100s in August for a completely different film. I was curious about testing their suitability for 3D, so I built a simple mounting plate with the help of my dad and his shop.
The concept is simple: Put two cameras as close together as possible (ideally 2.5 inches on the centre of the lens - human eye distance.) and shoot exactly the same frame. The HD100 has the ability to show a crosshair in the viewfinder, so this really helps adjusting each shot to converge on the object of interest.
The removable EVF also helps to line up the two cameras for each shot. I strapped them together with two elastic bands. It isn't pretty but it works.
I attached one quick release plate with two 3/8" screws and then the other was only attached at the front. This allowed one plate to swivel for convergence adjustment. I then used a simple eyehole tension adjuster ($2 at a hardware store) to make the convergence adjustments.
To record, I used free run timecode and set it to start as closely as my two hands could syncronize them. I then used a simple "clapper" to syncronize each shot to the frame.






So how did it work? Right now for landscape scenes it works really well, but I need to take the lens shades off and do some more modifications if I want to get those lenses closer for wide-angle close object shooting.

Here's 3 minutes of footage I created in After Effects with the 3D glasses plugin for anaglyph red/blue colour viewing. Our final screening will obviously be in a theatre with two projectors and polarized glasses, but this will give you an idea of the effectivness.
The file is 88Mb in quicktime H.264 codec at 720p24. You need a fast computer (or a mac) and Quicktime 7 to view it. I know the PC guys will complain a little, but it really is the best codec for getting material down to 2 or 3 Mbits/sec and maintain HD resolution. The source file looks amazing on my LCD monitor.

Download here:

http://homepage.mac.com/timdashwood/.Movies/3D_test.mov


For those without the bandwidth or inclination, I have posted a few jpeg screen grabs straight from after effects. If you don't have a pair of 3D anaglyph glasses (I calibrated these shots for the ones that come free with Spy Kids 3D DVD) then grab a Rosco or Lee gel swatch book and use a blue filter on your right eye and a red one on the left.

Enjoy! Tim
Attached Thumbnails
HD100 in 3D... grab your red/blue anaglyph glasses!-hd100-3d-test-1.jpg   HD100 in 3D... grab your red/blue anaglyph glasses!-hd100-3d-test-2.jpg

HD100 in 3D... grab your red/blue anaglyph glasses!-hd100-3d-test-3.jpg   HD100 in 3D... grab your red/blue anaglyph glasses!-hd100-3d-test-4.jpg

HD100 in 3D... grab your red/blue anaglyph glasses!-hd100-3d-test-5.jpg   HD100 in 3D... grab your red/blue anaglyph glasses!-hd100-3d-test-6.jpg

Tim Dashwood is offline   Reply With Quote
Old September 14th, 2005, 04:18 PM   #2
Major Player

Join Date: Dec 2003
Location: United Kindom, England
Posts: 290
Cool stuff, congrats on the setup!. Now I need to go find one of those funny coloured glasses.

Anhar Hussain
Anhar Miah is offline   Reply With Quote
Old November 14th, 2005, 11:39 AM   #3
Tourist

Join Date: Jun 2005
Posts: 3
Getting good anaglyph with JVC GY-HD100

Bravo...the stills look great from the JVC. Coincidently, I'm building a bit more
complex rig for a European company using the same cameras. The producer was going with Sony 1080i, but last week I convinced him to send the Sonys back and go with native progressive scan.Some of you,might know that I
manufacture plastic 3D anaglyph glasses under the "Anachrome trademark".
These are red-cyan glasses and let you see the full color spectrum better.
They correct the 250 nanometer wavelegth differential caused, focus shift,
which always softenes the view in the red filter. A whole lot of users strongly
advocate these glasses. The better color and more natural skin tones are
acquired at a cost; you can't have the cameras as far apart, because of a little increase in ghosting, as you broaden the spectrum. This closer spacing can be accomplished with "first surface mirrors" or "partial transmission
mirrors" in several ways. In general, you must reduce the spacing if there
is going to be distant b.grounds in a shot, with a main subject centered and closer. The normal eye distance is usually too much. also, toeing in for
overlay is not a good idea...better to do that in post. I'm going to Europe next week to shoot some tests with the client...you should see how good the
distant shots from the Canadian tests look with our glasses...again, BRAVO for the good work!
Allan Silliphant is offline   Reply With Quote
Old November 14th, 2005, 07:18 PM   #4
Major Player

Join Date: Oct 2005
Posts: 232
3d

Got out my Spy Kids glasses.
Looked pretty good!
Jon
Jon Jaschob is offline   Reply With Quote
Old November 15th, 2005, 07:55 AM   #5
Contributor

Join Date: Jul 2005
Location: Sydney Australia
Posts: 868
Quote:
Originally Posted by Tim Dashwood
Here's 3 minutes of footage I created in After Effects with the 3D glasses plugin for anaglyph red/blue colour viewing. Our final screening will obviously be in a theatre with two projectors and polarized glasses, but this will give you an idea of the effectivness.

Tim, if you're into 3D, I ran across the Sensio a while ago. Interesting technology - it uses LCD shutters in the glasses controlled by a sync pulse from the unit and the altenate frames are encoded into the 60i stream meaning it works with normal DVD players.

http://www.sensio.tv/en/home.htm
http://www.lenexpo-electronics.com/3dpro.php

You should go and read the interview with the guys who put the system together ..
http://www.sensio.tv/en/media_zone/W...view022004.pdf

shame I don't live near anywhere that could demo it and it is a trifle exe...
John Mitchell is offline   Reply With Quote
Old November 22nd, 2005, 06:42 PM   #6
Wrangler

Join Date: Aug 2005
Location: Toronto, ON, Canada
Posts: 3,637
As it turns out JVC has partnered with Sensio.
http://www.videography.com/articles/article_13798.shtml


Did anyone else watch the 3D episode of Medium last night on standard def? The 3D effect didn't work for me. The results were the same as my tests when I downconverted to a DVD and watched on an interlaced display. The 3D effect works great on a progressive display.

We're still working out the technical issues for our film, but it looks like 720P30 might be a better solution than 720P24 for 3D.

I'll keep everyone posted.
Tim Dashwood is offline   Reply With Quote
Old November 23rd, 2005, 07:31 AM   #7
Contributor

Join Date: Jul 2005
Location: Sydney Australia
Posts: 868
Quote:
Originally Posted by Tim Dashwood
As it turns out JVC has partnered with Sensio.
http://www.videography.com/articles/article_13798.shtml


Did anyone else watch the 3D episode of Medium last night on standard def? The 3D effect didn't work for me. The results were the same as my tests when I downconverted to a DVD and watched on an interlaced display. The 3D effect works great on a progressive display.

We're still working out the technical issues for our film, but it looks like 720P30 might be a better solution than 720P24 for 3D.

I'll keep everyone posted.
If it was just anaglyph glasses I'm not surprised - I can imagine the interlacing would really mess with the perception. From the sounds of the article I think the partnership was in supply of gear only - i.e. JVC provided the DILA projectors and Sensio provided the 3D expertise. I'm hunting round for those glasses my daughter has so I can watch your video Tim...
John Mitchell is offline   Reply With Quote
Old December 1st, 2005, 09:14 PM   #8
Inner Circle

Join Date: May 2005
Location: Burnaby, BC, Canada
Posts: 2,963
I've got 3D glasses from the game "Sly 3" and the depth is amazing! The next step in 3D technology is to somehow impliment polarization via a single projector/HDTV and a single screen.
__________________
I wait for the day cost-efficient global shutter 60fps capable CMOS sensors emerge for use on major manufacturers' cameras. (Sony, Canon, etc.) Rolling Shutters are a plague.
Jack Zhang is offline   Reply With Quote
Old December 22nd, 2005, 08:03 AM   #9
Major Player

Join Date: Oct 2005
Posts: 376
Hello,Tim!
Do you have 3D sample in over-under format 1280x1440 ?
What is minimum between centre of lenses you able get?
Serge Victorovich is offline   Reply With Quote
Old December 22nd, 2005, 09:41 AM   #10
Wrangler

Join Date: Aug 2005
Location: Toronto, ON, Canada
Posts: 3,637
Quote:
Originally Posted by Serge Victorovich
Hello,Tim!
Do you have 3D sample in over-under format 1280x1440 ?
What is minimum between centre of lenses you able get?
No. How would you view over-under?

The minimum lens centre distance I was able to get after removing the mic holder was 5 inches. Not bad, but double the ideal distance of 2.5 inches.
__________________
Tim Dashwood
Tim Dashwood is offline   Reply With Quote
Old December 22nd, 2005, 10:15 AM   #11
Major Player

Join Date: Oct 2005
Posts: 376
Tim, you can download trial of a great Stereoscopic Player, which is able to play stereoscopic video material in various formats (e.g. anglyph, side-by-side, over-under, dual screen output) using your favourite 3D glasses. Last version Stereoscopic Player 0.9.6 support separate left, right and audio files.
http://www.3dtv.at/Products/Player/Index_en.aspx
5 inch between two camcorders good only for landscape... But you can ask Allan Silliphant. He have solution:
Quote:
Unlike off the shelf JVC HDV camcorders, our rigs are genlocked for total sync accuracy, and use
special prime lenses for closer angles, rather than the 16 to 1 zoom used for longer distances.
The camera rigs allow closer spacing of the lenses than earlier crude, attempts to "twin" low cost cams.
Lens spacing is super-critical...make no mistake!
Good luck!
Serge Victorovich is offline   Reply With Quote
Old December 22nd, 2005, 10:30 AM   #12
Major Player

Join Date: Nov 2005
Location: Belgium
Posts: 695
Tim, when you used the dual-HD100 setup. How do you sync them up during recording?
Is there a way to sync through the firewire for example? It has a setting sync but that is probably for other purpose...
Marc Colemont is offline   Reply With Quote
Old December 22nd, 2005, 10:48 AM   #13
Wrangler

Join Date: Aug 2005
Location: Toronto, ON, Canada
Posts: 3,637
Quote:
Originally Posted by Marc Colemont
Tim, when you used the dual-HD100 setup. How do you sync them up during recording?
Is there a way to sync through the firewire for example? It has a setting sync but that is probably for other purpose...
I use free run TC and manually (with two hands) click preset execute at the same time. Of course, there is no way for this to be accurate enough to the frame, so I use a simple clapper slate. It works for sound and stereo picture!
__________________
Tim Dashwood
Tim Dashwood is offline   Reply With Quote
Old June 22nd, 2007, 11:42 AM   #14
Wrangler

Join Date: Aug 2005
Location: Toronto, ON, Canada
Posts: 3,637
I have since modified the HD100 dual rig by removing the zoom handle from the left lens and disassembling the right viewfinder. This allows me to get the two cameras much close, but I'm still no where near the 70mm interocular distance. I'm currently at about 120mm.

The next bit to remove is the little cube block that holds the microphone mount. This should give me another few millimeters, but I think I'll need to remove the Ab Gold mount bracket at the back to allow even closer configuration.

I shot another test in a cherry orchard with some very good depth. I just need to figure out a way to create the anaglyph version from within FCP and then I'll upload it. I hate moving it all over to After Effects just to use the 3D plugin.
I will post more photos within the week (I just have to take them.)
__________________
Tim Dashwood
Tim Dashwood is offline   Reply With Quote
Old July 30th, 2007, 02:11 PM   #15
Inner Circle

Join Date: Oct 2004
Location: Port St. Lucie, Florida
Posts: 2,614
Tim,

I appreciate your getting this forum started. I have been researching all over the place and did not find too much that appeared usable. Then I stumbled upon the info for 3D Glasses effect in my Premiere Pro software! DUH!!!!!

I had already dumped the footage I had shot, so will have to shoot it again. I set up a test camera set-up, using the CVC cameras. Nice 3" separation, but not that great of footage for sure. Just wanted to test it out before buying another HV20. I can set the the HV20s up at approximately 3 1/4" apart. That should work fine.

Prech Marton, who started another thread here, used the HV10s also. He is using a different method for production, which I don't understand, but I will work on that.

A question for you. The human eye does not look straight ahead, so would it be of any benefit to enable each camera to look at the same center as the human eye does, rather than straight ahead?

I look forward to reading all the post here. Still downloading your movie!!!!

Mike
__________________
Chapter one, line one. The BH.
Mike Teutsch is offline   Reply
