Old March 2nd, 2014, 02:03 PM   #1
Regular Crew

Join Date: Nov 2005
Location: Bremen, Germany
Posts: 176
BMPCC - Microphone Prototype


No Preamp, no battery. Only "PlugIn Power" from Pocket Camera.
__________________
Wolfgang Winne
www.ohrwurmaudio.de www.fxsupport.de
Wolfgang Winne is offline   Reply With Quote
Old March 3rd, 2014, 03:10 AM   #2
Inner Circle

Join Date: Feb 2009
Location: Brisbane, Australia
Posts: 2,261
Re: BMPCC - Microphone Prototype

It's quite a nice video, but I didn't see the microphone anywhere in it. :-P

(sounds great through my Event 20/20 monitoring speakers)

Andrew
Andrew Smith is offline   Reply With Quote
Old March 3rd, 2014, 03:28 AM   #3
Regular Crew

Join Date: Nov 2005
Location: Bremen, Germany
Posts: 176
Re: BMPCC - Microphone Prototype



1x Headphones, 1x Microphone



Prototype Mic... all sounds with pocket "100%" Level.

Mic (Version 1.0):
- Non-directional Stereo
- 10-18.000 Hz
- S/N Ratio 82 dB (1 kHz)
- max. Sound Level 120 dB S.P.L.
- Sensitivity -30 dB (1 kHz)
- 990 ľA Current Consumption (9V - ab 2V)
- Impedance ca. 3 kOhm
- Windshield

Stereo Headphones:
- Perfectly closed System for Sound record
- System 40mm, Dynamic
- Frequency Range 10- 20.000Hz
- Impedance 32 Ohm
- max. Input power 500mW
- Sensitivity 105 db / 1 mW
__________________
Wolfgang Winne
www.ohrwurmaudio.de www.fxsupport.de
Wolfgang Winne is offline   Reply With Quote
Old March 3rd, 2014, 07:23 AM   #4
Inner Circle

Join Date: Feb 2009
Location: Brisbane, Australia
Posts: 2,261
Re: BMPCC - Microphone Prototype

Interesting!

Just a thought: if the operator sneezes while recording .... it's going to be in stereo? :-)

Andrew
Andrew Smith is offline   Reply With Quote
Old March 3rd, 2014, 07:32 AM   #5
Regular Crew

Join Date: Nov 2005
Location: Bremen, Germany
Posts: 176
Re: BMPCC - Microphone Prototype

yes ;-)

__________________
Wolfgang Winne
www.ohrwurmaudio.de www.fxsupport.de
Wolfgang Winne is offline   Reply With Quote
Old March 3rd, 2014, 09:46 AM   #6
Major Player

Join Date: Sep 2013
Location: Perth, Western Australia.
Posts: 569
Re: BMPCC - Microphone Prototype

The Mouseketeers!!!
__________________
Cheers
Tim
Tim Lewis is offline   Reply With Quote
Old March 3rd, 2014, 09:58 AM   #7
Regular Crew

Join Date: Nov 2005
Location: Bremen, Germany
Posts: 176
Re: BMPCC - Microphone Prototype

The next prototype ;-)



Above: A two-horn system at Bolling Field, USA, in 1921. Acoustic radar.....
__________________
Wolfgang Winne
www.ohrwurmaudio.de www.fxsupport.de
Wolfgang Winne is offline   Reply With Quote
Old March 4th, 2014, 05:55 AM   #8
Major Player

Join Date: Nov 2008
Location: Melbourne Australia
Posts: 604
Re: BMPCC - Microphone Prototype

Hi Wolfgang,

I am a bit puzzled by your prototype pocket camera powered microphone as I did not think there was any power available from the BMPCC.

However I am impressed with the amount of detail and the shades of colour in your shots.

Were you using ProRes HQ or DNG and also what lens were you using?
Alastair Traill is offline   Reply With Quote
Old March 4th, 2014, 09:45 AM   #9
Regular Crew

Join Date: Nov 2005
Location: Bremen, Germany
Posts: 176
Re: BMPCC - Microphone Prototype

The BMPCC has 2.47 V PlugIn Power, no problem...

demo filmed in Prores "Film", 24 fps, 800ASA, Shutter Angle180, (100 Euro Lens) Olympus M.Zuiko Digital 14-42mm F1:3,5-5,6 - sharpness + color in Premiere Pro CS6.
__________________
Wolfgang Winne
www.ohrwurmaudio.de www.fxsupport.de
Wolfgang Winne is offline   Reply With Quote
Old March 4th, 2014, 10:12 AM   #10
Regular Crew

Join Date: Nov 2005
Location: Bremen, Germany
Posts: 176
Re: BMPCC - Microphone Prototype



Prototype: Today testing the ultmativ windshield...

http://www.fxcinema.de/temp/wind.mp3 (windmachine with 3 m/s)

Left Channel with new windshield, right channel only pop-filter.


__________________
Wolfgang Winne
www.ohrwurmaudio.de www.fxsupport.de

Last edited by Wolfgang Winne; March 4th, 2014 at 11:29 AM.
Wolfgang Winne is offline   Reply With Quote
Old March 5th, 2014, 01:33 AM   #11
Major Player

Join Date: Nov 2008
Location: Melbourne Australia
Posts: 604
Re: BMPCC - Microphone Prototype

Thanks Wolfgang,

Interesting, I have tested the same lens but was very disappointed with its sharpness and I returned it to my supplier. At that stage I did not add any sharpening which I am now trying with other lenses.
Alastair Traill is offline   Reply With Quote
Old March 5th, 2014, 02:25 AM   #12
Regular Crew

Join Date: Nov 2005
Location: Bremen, Germany
Posts: 176
Re: BMPCC - Microphone Prototype

O.K. Metabones speedbooster with Nikon Lens are sharper....

here my Olympus digital M.ZUIKO 14-42mm 1:3.5 with BMPCC



pure sharpness with BMPCC/Speedbooster/Nikon 60mm

__________________
Wolfgang Winne
www.ohrwurmaudio.de www.fxsupport.de
Wolfgang Winne is offline   Reply With Quote
Old March 6th, 2014, 12:11 AM   #13
Major Player

Join Date: Nov 2008
Location: Melbourne Australia
Posts: 604
Re: BMPCC - Microphone Prototype

Hi and thanks again Wolfgang,

More contrast and a bit more definition with the Nikon, is it the 60mm Micro Nikkor? What should I think about the colour patterns?
Alastair Traill is offline   Reply With Quote
Old March 6th, 2014, 07:30 PM   #14
Regular Crew

Join Date: Apr 2009
Location: Toronto Canada
Posts: 71
Re: BMPCC - Microphone Prototype

I don't quite understand this topic, is it because you are going to try to sell the mic setup and are keeping what it all is a secret for now?

Anyways the sound sounds amazing to me so if you will ever share what it is and how to set it up please tell me as I would like to see how much all the pieces cost and if it is practical to build one myself, whatever it is that is.
Dylan Tobias is offline   Reply With Quote
Old March 7th, 2014, 12:37 AM   #15
Major Player

Join Date: Nov 2008
Location: Melbourne Australia
Posts: 604
Re: BMPCC - Microphone Prototype

Dylan,
I am guilty of taking this thread off topic but I have also wondered about its original purpose. In the absence of any other information it looks as though the headphone diaphragms are being used as microphones with their outputs being fed into the BMPCC mic input. This would explain the placement of the wind protection fur patches but not the power consumption.
Alastair Traill is offline   Reply
