Canon 16-35mm f/2.8 L II hot spot?

I just received this lens new and after using it today with my C100 I notice a bright white/blue spot distinct from flare when the sun is shining from the side and then moving the camera toward the sun. It goes away when there is no bright light source. Pointing the camera at my neighbor's grey wall I can see the spot even when there is no lens flare, it looks strange. It is not a stuck pixel and ABB does not change the presentation, nor does a change in ISO. Is this common with this lens or could this be a flaw with this particular unit? I'm thinking of returning it.
Mervin Langley is offline   Reply With Quote
Old February 24th, 2014, 09:20 AM   #2
Regular Crew

Join Date: Mar 2012
Location: Princeton, NJ
Posts: 110
Re: Canon 16-35mm f/2.8 L II hot spot?

I have shot a lot with the 16-35 II, stills (1DsM3, 5DM3, 1D X) and video (C300), and have never noticed anything like that. Doesn't sound normal.

You could try it on another body. Can you post a frame grab of what you are seeing?

Also, is there a filter on a the lens? Could be an internal reflection from a screw-on filter.
__________________
Site | Blog
Instagram
Jon Roemer is offline   Reply With Quote
Old February 25th, 2014, 09:17 PM   #3
Regular Crew

Join Date: May 2008
Location: Burlington, Wisconsin
Posts: 137
Re: Canon 16-35mm f/2.8 L II hot spot?

Here is a screen shot. The bright spot is over the street but on further review I suspect it is an example of the 16-35 II's poor flare issue. As I panned over toward the sun the flare was more obvious and included additional flare spots.
Mervin Langley is offline   Reply With Quote
Old February 26th, 2014, 09:21 PM   #4
Trustee

Join Date: Jan 2006
Location: New York, NY
Posts: 1,267
Re: Canon 16-35mm f/2.8 L II hot spot?

Is there a link to the screen shot?
Daniel Epstein is offline   Reply With Quote
Old February 26th, 2014, 11:49 PM   #5
Trustee

Join Date: Nov 2006
Location: Honolulu, HI
Posts: 1,430
Re: Canon 16-35mm f/2.8 L II hot spot?

I also have a 16-35 but never noticed any problem like yours. See if you can isolate the problem:
1. Take off the lens. Peer through the back of the lens and look at a low light source such as a lamp. The glass should appear clear.
2. Position the camera on a tripod so you see the maximum flare you describe. Lock the camera down. Without moving the camera body, turn the focus manually. Does the flare rotate with the lens? If yes, then the problem is in your front element. If no, then...
3. Shade the camera and lens with a piece of cardboard, then move it slowly left/right. Check to see if there is a light leak somewhere on the lens barrel itself, between the lens and the body, or between the lens shade and the lens.
4. Try different apertures to see what f-stop maximizes the flare.

Hopefully you'll be able to determine where the flare is coming from and what is causing it.
Warren Kawamoto is offline   Reply With Quote
Old February 27th, 2014, 12:42 AM   #6
Regular Crew

Join Date: May 2008
Location: Burlington, Wisconsin
Posts: 137
Re: Canon 16-35mm f/2.8 L II hot spot?

Quote:
Originally Posted by Mervin Langley View Post
Here is a screen shot. The bright spot is over the street but on further review I suspect it is an example of the 16-35 II's poor flare issue. As I panned over toward the sun the flare was more obvious and included additional flare spots.
Here is the screenshot. Somehow I did not upload it before. Thanks for the information I will try it this weekend if Wisconsin ever warms up.
Attached Thumbnails
Canon 16-35mm f/2.8 L II hot spot?-image17-copy.jpg
Mervin Langley is offline   Reply With Quote
Old February 27th, 2014, 12:56 AM   #7
Major Player

Join Date: Jul 2010
Location: Montreal
Posts: 388
Re: Canon 16-35mm f/2.8 L II hot spot?

For medium-wide lenses thats actually really good flare control. Minimal to no halos, not a lot of contamination otherwise. If your main cause for concern is that singular hotspot in the middle of the frame... then correct it in post. If I got plates that clean on a normal basis I would be damn happy. If this is underneath your standards I would really like to see what glass you have been shooting with beforehand.
__________________
Automotive Multimedia
Justin Molush is offline   Reply With Quote
Old February 27th, 2014, 08:19 AM   #8
Regular Crew

Join Date: Mar 2012
Location: Princeton, NJ
Posts: 110
Re: Canon 16-35mm f/2.8 L II hot spot?

Quote:
Originally Posted by Mervin Langley View Post
Here is the screenshot. Somehow I did not upload it before. Thanks for the information I will try it this weekend if Wisconsin ever warms up.
The flare in that screen grab is *normal and quite well controlled as others have said.

*Assuming it's coming from the sun in the frame. In your original post you said it was visible when pointed at a wall - if that's the case, and it's the same then that could be an issue but that is what you need to test.
__________________
Site | Blog
Instagram
Jon Roemer is offline   Reply
