Macro-Closeup Videography HOW?

I capture footage for educational videos for an engine comapny. I need to be able to get closeups of items such as throttle cables, casting numbers, Serial Numbers, etc, What do I need or how do i do this?
David Ruhland is offline   Reply With Quote
Old April 18th, 2008, 08:57 PM   #2
Major Player

Join Date: Jun 2007
Location: Bay Area, CA, USA
Posts: 348
I would use some +3 or +4 close up lenses. With a 52mm step-up ring you can buy cheap Tiffen close-up lens-filters, they usually costs about $25. I shot this video with them and the HV20: http://vimeo.com/678941

Alternatively, you can get a Canon 50/1.8 lens, mounted using a 52mm reverse ring (found at B&H). I have a picture of my setup here: http://eugenia.gnomefiles.org/2007/11/28/a-new-rig/
This is more difficult to use btw than close-up filter-lenses, but not impossible. It all depends how much you want to zoom in.
Eugenia Loli-Queru is offline   Reply With Quote
Old April 18th, 2008, 09:17 PM   #3
Obstreperous Rex

Join Date: Jan 2001
Location: San Marcos, TX
Posts: 26,900
Images: 513
Zoom out to full wide and provide plenty of light. Bring the camera close to the object. The camera will focus on things right up to the front of the lens. This macro capability is built in and readily available as long as you're zoomed out to full wide angle.
__________________
CH

Search DV Info Net | DV Info Net Sponsors | A Decade (+5) of DVi | ...Tuesday is Soylent Green Day!
Chris Hurd is offline   Reply With Quote
Old April 18th, 2008, 09:39 PM   #4
Major Player

Join Date: Oct 2007
Location: Paradise, california
Posts: 353
you might want to also consider using a still camera for some of the closeup detailed shots, and then zooming in and moving in post. It might take a little longer to match colors, but it could give you extreme detail with no camera shake. and If this is not a good idea, I would love to hear the reasons I am wrong :)
__________________
"What I need is an exact list of specific unknown problems we might encounter."
Allen Plowman is offline   Reply With Quote
Old April 19th, 2008, 05:48 AM   #5
New Boot

Join Date: Jan 2008
Location: Birmingham, UK
Posts: 16
For the best results use manual focus and a tripod or a monopod. A good external lighting is also welcomed since getting close to an object usually obstruct available light. Of course zooming out is a must as mentioned above, and a closeup (macro) lens is a welcomed addition and will make the thing easier.
Moayad Hassan is offline   Reply With Quote
Old April 19th, 2008, 09:27 PM   #6
Major Player

Join Date: Dec 2007
Location: Madison WI
Posts: 340
Quote:
Originally Posted by Eugenia Loli-Queru View Post
I would use some +3 or +4 close up lenses. With a 52mm step-up ring you can buy cheap Tiffen close-up lens-filters, they usually costs about $25. I shot this video with them and the HV20: http://vimeo.com/678941

Alternatively, you can get a Canon 50/1.8 lens, mounted using a 52mm reverse ring (found at B&H). I have a picture of my setup here: http://eugenia.gnomefiles.org/2007/11/28/a-new-rig/
This is more difficult to use btw than close-up filter-lenses, but not impossible. It all depends how much you want to zoom in.
I have a Nikon 50 mm lens, this would work too wouldnt it? Does it have to be a "macro" lens or will any 50mm work?
David Ruhland is offline   Reply With Quote
Old April 19th, 2008, 10:23 PM   #7
Obstreperous Rex

Join Date: Jan 2001
Location: San Marcos, TX
Posts: 26,900
Images: 513
How's this for built-in macro capability (click to see 'em big)...
Attached Thumbnails
Macro-Closeup Videography HOW?-img_0109.jpg   Macro-Closeup Videography HOW?-img_0111.jpg

__________________
CH

Search DV Info Net | DV Info Net Sponsors | A Decade (+5) of DVi | ...Tuesday is Soylent Green Day!
Chris Hurd is offline   Reply With Quote
Old April 20th, 2008, 09:01 AM   #8
Major Player

Join Date: Dec 2007
Location: Madison WI
Posts: 340
Chris..

Thats impressive.. gonna play a lil with it today... Dont mean to get off the subject here and post in the wrong forum, but does the GL2 have a similer capability?

thanks..
David Ruhland is offline   Reply With Quote
Old April 20th, 2008, 10:33 AM   #9
Obstreperous Rex

Join Date: Jan 2001
Location: San Marcos, TX
Posts: 26,900
Images: 513
Hi Dave, take the lens hood off of your GL2, provide plenty of light, zoom out to full wide and you can focus on objects touching the front of the lens.
__________________
CH

Search DV Info Net | DV Info Net Sponsors | A Decade (+5) of DVi | ...Tuesday is Soylent Green Day!
Chris Hurd is offline   Reply
