HV20 and Sony wide angle Lens tests

I've just been trying my HV20 with a Sony VCL-MHG07 wide-angle lens (using a 43-52mm step up ring).

Here are some screenshots:











Fergus Anderson is offline   Reply With Quote
Old July 10th, 2007, 08:56 AM   #2
Regular Crew

Join Date: Jun 2005
Location: Niagara, Ontario
Posts: 141
you may want to repost those images, you didn't use the correct links, those are just mini thumnails, way to small to see any detail
Jay Cowley is offline   Reply With Quote
Old July 10th, 2007, 09:37 AM   #3
Regular Crew

Join Date: May 2007
Location: Addison, Texas
Posts: 178
Hey Fergus...many thanks for posting these. I'm very impressed with the images taken with the Sony lens and think I'll look into getting one as well...unless others have a better alternative for a same-priced lens.
Nathan Shane is offline   Reply With Quote
Old July 10th, 2007, 09:53 AM   #4
Major Player

Join Date: Nov 2006
Location: London, UK
Posts: 321
Quote:
Originally Posted by Jay Cowley View Post
you may want to repost those images, you didn't use the correct links, those are just mini thumnails, way to small to see any detail
Jay

Just left click on each thumnail and it will hyperlink to the full size image

Nathan, thanks - I think the results are pretty good. My main concern was sharpness but I am satisfied with that. I have posted the raw footage on another forum (not sure I can link from here)
Fergus Anderson is offline   Reply With Quote
Old July 10th, 2007, 10:24 AM   #5
Regular Crew

Join Date: May 2007
Location: Addison, Texas
Posts: 178
Have you tried any closeups with wideangle lens?
Nathan Shane is offline   Reply With Quote
Old July 10th, 2007, 10:29 AM   #6
Major Player

Join Date: Nov 2006
Location: London, UK
Posts: 321
No not yet, just got my step up ring today. Any particular scenario you would like to see?
Fergus Anderson is offline   Reply With Quote
Old July 10th, 2007, 10:38 AM   #7
Inner Circle

Join Date: Nov 2005
Location: Elk Grove CA
Posts: 6,838
I have had some pleasing results with a Kenko .7 wide I have used on my VX2000 for years. I use a 43mm to 58mm step down to match it. I will try to post some stills tonight. Being designed for SD, it still seems to provide a decent picture for a wide angle shot. It does appear to soften the image a bit, but that is not all bad, in terms of filmic qualities.

I also use a 58mm Sony 1.7 teleextender on the other end, again originally purchased for the VX2000. CA is a big problem at the extreme end of the telephoto range with that lens.
__________________
Chris J. Barcellos
Chris Barcellos is offline   Reply With Quote
Old July 10th, 2007, 10:43 AM   #8
Regular Crew

Join Date: May 2007
Location: Addison, Texas
Posts: 178
Quote:
Originally Posted by Fergus Anderson View Post
No not yet, just got my step up ring today. Any particular scenario you would like to see?
Hmm...perhaps something that has a primary character dog/cat/fire-hydrant/mailbox ??? and a couple other interesting subjects further away (but not far away) in the background. I guess I'd like to see some DOF and how closer subjects actually look in comparison to that which is behind/around them. And pick some odd angles to capture from to help exaggerate the perspective somewhat. And maybe primary subject is drastically different in color(s) compared to background secondary subjects. Okay...that's a lot to ask for. Just do whatever you feel like doing. LOL!!!
Nathan Shane is offline   Reply With Quote
Old July 10th, 2007, 02:48 PM   #9
Major Player

Join Date: Nov 2006
Location: London, UK
Posts: 321
Ok here are a few closeup shots with the Sony lens

If you would like the footage just give me a PM since its on another forum and I dont think Chris would like me to link to it. I think on the whole the images are very sharp closeup. The camera in normal autofocus does take a while to focus if the position of the subject changes quickly. Sorry for the lack of imagination with the shots, only had a few minutes in between changing baby!

Let me know what you think
Cheers
Ferg















Fergus Anderson is offline   Reply With Quote
Old July 10th, 2007, 03:06 PM   #10
Inner Circle

Join Date: Mar 2003
Location: Billericay, England UK
Posts: 4,711
I always reckon it's barrel distortion that spoils many a wide-angle converter, and door frames that bow outwards as you track room to room look horribly amateurish in my book. None of the posted images show straight lines that don't pass through the middle of the frame, and this is the great barrelling test.

tom.
Tom Hardwick is offline   Reply With Quote
Old July 10th, 2007, 03:17 PM   #11
Regular Crew

Join Date: May 2007
Location: Addison, Texas
Posts: 178
I like the next to last image with the garden tool best...it shows the depth I was curious about. And the one with the green leaf, I like that as well. Thanks! You've shown me what I was wanting to see.
Nathan Shane is offline   Reply With Quote
Old July 10th, 2007, 03:26 PM   #12
Major Player

Join Date: Nov 2006
Location: London, UK
Posts: 321
Quote:
Originally Posted by Tom Hardwick View Post
I always reckon it's barrel distortion that spoils many a wide-angle converter, and door frames that bow outwards as you track room to room look horribly amateurish in my book. None of the posted images show straight lines that don't pass through the middle of the frame, and this is the great barrelling test.

tom.
Tom, sorry what would you like me to shoot? Door frames at the edge of the picture to test how straight they are?

Cheers
Fergus Anderson is offline   Reply With Quote
Old July 10th, 2007, 05:35 PM   #13
Inner Circle

Join Date: Nov 2005
Location: Elk Grove CA
Posts: 6,838
Quote:
Originally Posted by Tom Hardwick View Post
I always reckon it's barrel distortion that spoils many a wide-angle converter, and door frames that bow outwards as you track room to room look horribly amateurish in my book. None of the posted images show straight lines that don't pass through the middle of the frame, and this is the great barrelling test.

tom.
Tom:

I think the HV20 at the wide angle range has a about the equivalent of a 32 mm 35mm SLR lens. So if you slap a .7 on that end, are you enevitably doomed to seeing barrelling ?
__________________
Chris J. Barcellos
Chris Barcellos is offline   Reply With Quote
Old July 10th, 2007, 09:41 PM   #14
Inner Circle

Join Date: Nov 2005
Location: Elk Grove CA
Posts: 6,838
For your comparison, here are jpegs of Shots with my HV20 with the Kenko Pro 65 which is a .65 x, not .7. All shots were at widest angle setting.

Lens is Kenko KRW-065 Pro II 0.65x
Attached Thumbnails
HV20 and Sony wide angle Lens tests-img_0156.jpg   HV20 and Sony wide angle Lens tests-img_0154.jpg

HV20 and Sony wide angle Lens tests-img_0159.jpg   HV20 and Sony wide angle Lens tests-img_0160.jpg

HV20 and Sony wide angle Lens tests-img_0163.jpg   HV20 and Sony wide angle Lens tests-img_0155.jpg

__________________
Chris J. Barcellos
Chris Barcellos is offline   Reply With Quote
Old July 11th, 2007, 06:23 AM   #15
Major Player

Join Date: Nov 2006
Location: London, UK
Posts: 321
nice shots Chris, it does look a little wider than mine.
