Nightvision Preset?

Hello :-)

Does anyone have a nightvision preset for sharing?
(u know the green-ish night colour)

/thx

PS... the picture is from Chris Cunninghams - Rubber Johnnny

that is what i'm looking for
Attached Images

Liam Nazemi is offline   Reply With Quote
Old June 3rd, 2007, 04:28 PM   #2
Trustee

Join Date: Dec 2006
Location: Little Rock
Posts: 1,383
I do not know of a "Nightvision Preset" for the G1/A1.
But here is a link to a camera that has 0 Lux Night Vision built it.

http://www.dvinfo.net/conf/showthread.php?t=95383
David W. Jones is offline   Reply With Quote
Old June 3rd, 2007, 04:49 PM   #3
Regular Crew

Join Date: Apr 2007
Location: Toronto Canada
Posts: 27
i dont think that would be in the presets.

it would be a function.

a fuction that the XH-A1 doesnt have
__________________
XH-A1
Andrew McDowell is offline   Reply With Quote
Old June 3rd, 2007, 05:07 PM   #4
Tourist

Join Date: Feb 2007
Location: Stockholm
Posts: 4
I know that the XH A1 dosent have night vision...

But u could fake it... and use a night-ish lookalike preset?
Liam Nazemi is offline   Reply With Quote
Old June 3rd, 2007, 05:08 PM   #5
Major Player

Join Date: Dec 2006
Location: Los Angeles, CA
Posts: 959
Just do it in post. B&W with a slight greenish tint, nudge luma & gamma a bit, add a vignette filter & maybe add some noise, or shoot in high gain... cut out a render middleman :D

Bill
Bill Busby is offline   Reply With Quote
Old June 3rd, 2007, 08:07 PM   #6
New Boot

Join Date: May 2007
Location: Austin, Texas
Posts: 17
Night Vision

I actually have one I set up last week end for a simulation in a movie it worked great. It is desgined to work with 4 tungsten 40 watt floods about 15 feet apart. It was great because the actors could see what they were doing but it gave you the feeling you were in total darkness. Send me your email and I'll send it to you.

Wynn B

wbradford@dtwproductions.com
Wynn Bradford is offline   Reply With Quote
Old June 5th, 2007, 08:38 AM   #7
Disjecta

Join Date: Apr 2004
Location: Seattle, Washington
Posts: 937
Wynn, unless there is a specific reason you can't, it would be great if you would share it with the rest of the board by posting in the presets section of this forum.

thanks
__________________
Try my Digital Therapy: http://www.pinelakefilms.com/digital_therapy.html
Films on ExposureRoom: http://exposureroom.com/members/disjecta.aspx/videos/
Steven Dempsey is offline   Reply With Quote
Old June 5th, 2007, 10:41 AM   #8
New Boot

Join Date: May 2007
Location: Austin, Texas
Posts: 17
Night Vision

Sure I'll do it as soon as I get home this evening. I have a real night scope so I set it up as close to it as I could.

Wynn B
Wynn Bradford is offline   Reply With Quote
Old June 5th, 2007, 10:15 PM   #9
New Boot

Join Date: May 2007
Location: Austin, Texas
Posts: 17
Preset

Sorry guys but I cannot figure out how to upload or I may not be allowed.
Thanx for any help.

Wynn B
Wynn Bradford is offline   Reply With Quote
Old June 5th, 2007, 11:13 PM   #10
Wrangler

Join Date: Oct 2003
Location: DFW area, TX
Posts: 6,108
Images: 1
Quote:
Originally Posted by Wynn Bradford View Post
Sorry guys but I cannot figure out how to upload or I may not be allowed.
Thanx for any help.
When posting a message, look below the text window under Additonal Options. You should see a box labeled Attach Files with a 'Manage Attachments' button. Click that and you'll see a bunch of 'choose file' buttons. Click the first one, select the file from your system and upload it by selecting the 'upload' button. Wait until it's finished, then close the window. At that point, you can 'submit reply' as you normally would.

Hope this helps,

-gb-
Greg Boston is offline   Reply With Quote
Old June 6th, 2007, 12:49 AM   #11
Major Player

Join Date: Dec 2006
Location: Los Angeles, CA
Posts: 959
Greg, he may not have been here long enough. I recall there being a somewhat good while for me after becoming a member here before I could upload anything. The posting rules at the bottom right dictate what can & cannot be done for a user.

Wynn, at the very least (until you get upload privileges), you could type the settings changed according to the CP menu for those interested in this preset. Of course this takes a bit of time though :)

Bill
Bill Busby is offline   Reply With Quote
Old June 6th, 2007, 07:12 PM   #12
New Boot

Join Date: May 2007
Location: Austin, Texas
Posts: 17
Night Vision

Here we go..
GAM:N ,KNE:A ,BLK:S ,PED:6 ,SET:0 ,SHP:-9 ,HDF:M , DHV:0 ,COR:-9 ,NR1:OFF , NR2:OFF ,CMX:N , CGN:-32 ,CHP:0 ,RGN:-50 ,GGN:21 , BGN:-50 ,RGN:-50 ,RBM:-50 ,GRM:-50 ,GBM:-50 ,BRM:-50 ,BGM:-50

AGC:OFF ,GAIN:H ,AF:M ,AWB:OFF ,WBPreset:Tungsten ,AE SHIFT:-0.25 ,GAIN SETTING(Menu) 12db

Use weak floods and try to avoid black shadows because in real low light there are none.

Good Shooting

Wynn Bradfored
Wynn Bradford is offline   Reply With Quote
Old June 12th, 2007, 02:48 AM   #13
Tourist

Join Date: Feb 2007
Location: Stockholm
Posts: 4
thx for the feedback,...

i will send u an email Wynn

cheers!
Liam Nazemi is offline   Reply With Quote
Old June 12th, 2007, 07:30 AM   #14
Obstreperous Rex

Join Date: Jan 2001
Location: San Marcos, TX
Posts: 26,900
Images: 513
Try again, Wynne -- you should be able to upload attachments now.
__________________
CH

Search DV Info Net | DV Info Net Sponsors | A Decade (+5) of DVi | ...Tuesday is Soylent Green Day!
Chris Hurd is offline   Reply With Quote
Old June 12th, 2007, 07:43 AM   #15
New Boot

Join Date: May 2007
Location: Austin, Texas
Posts: 17
Night Vision Preset

Oh guys and Gals her it is ......I hope!

Wynn B
Attached Files
File Type: cpf PRESET19.CPF (40 Bytes, 204 views)
