Old September 25th, 2006, 04:25 PM   #91
New Boot

Join Date: Apr 2005
Location: Gulf Breeze FL
Posts: 12
Thank you

I'll try again when I get home to my PC. Do they have this for MAC? I live in both worlds.
David Heroux is offline   Reply With Quote
Old September 25th, 2006, 09:20 PM   #92
New Boot

Join Date: Apr 2005
Location: Gulf Breeze FL
Posts: 12
Works Great

I downloaded it this evening. It is going to come in very handy.
Thanks
David Heroux is offline   Reply With Quote
Old October 11th, 2006, 01:26 PM   #93
Regular Crew

Join Date: Sep 2006
Location: Milford Michigan
Posts: 38
Any tips on shooting 24P inside homes & outside?

Ash;

do you recommend any Custom Settings for working indoors(under household flourescent light), as well as outside (filming houses, pool areas). I currently shoot a real estate show with an XL-2, and am having trouble finding the exact best settings to bring out the details, as well as when I pan(stuttered effect of 24P when I watch thru LCD tv). Is the stuttered effect just because I'm looking at it thru a tv, before its edited through VEGAS?
I would love to know the best settings for indoors for b-roll 24P, interviews indoors & out, as well as just filming the houses outdoors.
If I can get the pans to look like the pans in 60I, we plan to shoot everything for the show in 24P.
I want the b-roll footage to have tons of detail, & the interviews to be a little softer in tone.
thanks;

Peter V.
Peter Vaughn is offline   Reply With Quote
Old October 12th, 2006, 12:32 AM   #94
Trustee

Join Date: May 2003
Location: Tulsa, OK
Posts: 1,689
Make sure you OIS is off... make sure your shutter is 1/48th... make sure your pans are smooth and not too fast. If you are doing it for domestic TV, you may consider 30p which will give you nice progressive images but less motion blur.



ash =o)
Ash Greyson is offline   Reply With Quote
Old April 22nd, 2007, 06:22 PM   #95
New Boot

Join Date: Feb 2007
Location: Los Angeles, CA
Posts: 5
I'm actually having a problem installing the drivers for the program, sadly. I am running Windows XP x64, and when I am defining the correct folder to locate the drivers for the XL2 (as detailed in the Installation instructions), I receive the message "The Hardware was not installed because the wizard cannot find the necessary software. If a driver was provided, make sure it is designed to work with Windows for x64-based systems."

Is this program and the attached drivers NOT compatible with Windows XP x64 edition?? Thanks for your help!
Matt Mercer is offline   Reply With Quote
Old May 16th, 2007, 01:23 AM   #96
New Boot

Join Date: Jun 2006
Location: San Francisco, CA
Posts: 22
Vista compatible?

The XL2 Presets Manager wouldn't happen to be compatible with Windows Vista would it?
I don't want to DL it if it isn't.

Thanks
Lee
Lee Stokes is offline   Reply With Quote
Old May 22nd, 2007, 03:29 PM   #97
New Boot

Join Date: May 2007
Location: Seattle, WA
Posts: 15
I'm also trying to get the presets manager working (everyone raves about it and it is easier than handwriting everyone's recommended presets), but I also have Vista and got the device drivers working, but I cannot get the program to read preset 1/2/3. Any ideas if they are compatible? Or how to get around this problem?
Jennifer Eidum Zinchuk is offline   Reply With Quote
Old May 23rd, 2007, 06:01 AM   #98
Regular Crew

Join Date: Apr 2007
Location: Muskegon, Michigan
Posts: 75
Quote:
Originally Posted by Peter Vaughn View Post
Ash;

do you recommend any Custom Settings for working indoors(under household flourescent light), as well as outside (filming houses, pool areas). I currently shoot a real estate show with an XL-2, and am having trouble finding the exact best settings to bring out the details, as well as when I pan(stuttered effect of 24P when I watch thru LCD tv). Is the stuttered effect just because I'm looking at it thru a tv, before its edited through VEGAS?
I would love to know the best settings for indoors for b-roll 24P, interviews indoors & out, as well as just filming the houses outdoors.
If I can get the pans to look like the pans in 60I, we plan to shoot everything for the show in 24P.
I want the b-roll footage to have tons of detail, & the interviews to be a little softer in tone.
thanks;

Peter V.
I have a question for you as another fellow Vegas user.

When you render, do you set your frame rate to 24 (film) or do you leave it at NTSC?
Chris C. Collins is offline   Reply With Quote
Old June 17th, 2007, 10:51 PM   #99
New Boot

Join Date: Jun 2007
Location: Perth Western Australia
Posts: 38
Identity presets

Hullo! New XL2 user, here, still getting used to things. My partner and I will be fiddling with the presets to see what we can get out of them, but at the moment we are still trying to figure out what does what. We'll share what we get.

In the meantime, anyone want to give a crack at an Identity preset?
http://us.imdb.com/gallery/ss/030969...hint=nm0000131

At first I thought the colour was a little washed out, but there are some beautiful golden tones, which seem to conflict greatly with the very silver look of the film. I know enough to figure a good wack of it is lighting, but there may be some in camera tricks we can use.
Jasmine Marie Adams is offline   Reply With Quote
Old October 25th, 2007, 11:37 AM   #100
Regular Crew

Join Date: Mar 2006
Location: Chicago, Illinois
Posts: 93
i think one thing i would be interested in finding out is doing HDR with the XL2. Is it possible doing HDR with DV video?
__________________
"Tomorrow Never Comes Until Its Too Late"-DJ Shadow
Michael Krumlauf is offline   Reply With Quote
Old January 4th, 2008, 01:07 PM   #101
Regular Crew

Join Date: Jul 2007
Location: Cph Denmark
Posts: 136
New Presets

Hey guys, so maybe its my turn to chip in.

I would use the preset manager, if it dident make a runtime error everytime I try to use it, so I guess I have to do it like in the ole days. If someone can transfer those numbers into a preset file. It would be appreciated.

I got 3 presets for you, that I created for general use.

These presets are intended to setup the XL2 for 3 different light conditions, but without "burning" a specific look into an irreversible state. In other words those presets will not give you the film look, or any other specific look, but instead it will give you the best (well as good as I can tell) footage, before you go in your editing studio to tweak the final look and mood.

Preset1:
Optimal light conditions such as in a studio. For this setting I used a pair of 5000 kelvin daylight bulbs (I think they are called flourecent studio lights)

Gain: -3

Gamma: Cine
Knee: High
Black: press

Color matrix: Cine
Color Gain: 0
Color Phase: 0

R: 0
G: 0
B: 0

V detail: Normal

Sharpness: 0
Coring: 0

Setup Level: -3
Master Ped: -4
Nr: off

This preset could also be used for outdor shooting on a good sunny day.
Remember to use your ND filter tho.


Preset 2:
Good lighting conditions, but not near as controled like preset 1. This should be mainly used for arenas, concert halls, or other indor enviroments where the ligthing is ok.

Gain: 0

Gamma: Cine
Knee: High
Black: Middle

Color matrix: Cine
Color Gain: 0
Color Phase: 0

R: 0
G: 0
B:-2

V detail: Normal

Sharpness: 0
Coring: 0

Setup Level: 0
Master Ped: 0
Nr: low


Preset 3:
This preset is specialized for really dark scenes. I have been shooting quite a lot of event shows at night clubs, where in some instances the only light available is the Video light on my XL2. In other words. If you have to shoot with +12 gain. Use this preset.

Gain: 12

Gamma: Cine
Knee: Middle
Black: Stretch

Color matrix: Cine
Color Gain: 0
Color Phase: 0

R: 0
G: 0
B:-2

V detail: Normal

Sharpness: -2
Coring: 0

Setup Level: -3
Master Ped: 0
Nr: High

Some of you might be asking, why I use the Cine gamma in such a dark enviroment, when the normal mode brightens the overall image.
Thats true, but even tho the image becomes slightly darker with Cine Gamma, it also removes lots of noise from the shadow areas. And you can always brighten the footage in your NLE to compensate if needed. Still you will end up with a more clean result, than if you dident use Cine Gamma.
Overall you might just as well crush the blacks in dark conditions, cause you will not get any detail of them anyways. Just like the spotlight mode.
Nik Skjoth is offline   Reply With Quote
Old August 12th, 2008, 11:47 PM   #102
New Boot

Join Date: Mar 2008
Location: Perth Western Australia
Posts: 10
preset xl2

Hi all ,i have sent a pm to Ash but he is a busy man and may not get it in time .
I have been thrown in the deep end with a rush job tomorrow filming racing cars, choppers , boats hi action thing. My thing is doco so has to rethink my presets . The question The sport preset looks to be the goods was wondering if any one could offer advice I shoot Pal its for broadcast TV will 50dpi be okay its a small change from the preset.
Ian Hollow is offline   Reply With Quote
Old August 13th, 2008, 05:41 AM   #103
Regular Crew

Join Date: Jan 2008
Location: Sweden
Posts: 41
I have started using more detail after som lookaround in the forum.

Now using:

Gain: -3

Gamma: Cine
Knee: LOW
Black: STRECH

Color matrix: Cine
Color Gain: +1
Color Phase: +1

R: +1
G: 0
B: 0

V detail: LOW

Sharpness: +3
Coring: 0

Setup Level: -4 / -6
Master Ped: -3
Nr: off

It's nice to see how well the cam uses high detail settings. If I compare to my previous DVX100A the grain would stand out with the Pana cam.
Off cource viewing this on a broadcast monitor makes it look even better. This was shot handheld from the waist. Lens was 16X manual.
Attached Thumbnails
A tip on custom settings....-untitled-2.png   A tip on custom settings....-untitled-1.png

A tip on custom settings....-untitled-3.png

Last edited by David Odell; August 13th, 2008 at 09:40 AM.
David Odell is offline   Reply With Quote
Old August 14th, 2008, 04:08 AM   #104
Major Player

Join Date: Feb 2005
Location: Rochester, NY
Posts: 263
Hello,

Great detail with the cat!

I find that when I'm shooting general topics for my corporate work that I have ti soften the sharpness to eliminate shimmer. SD DV has many challenges like stair stepping, bending off lines, etc. although shimmering is not limited to DV, it seems to be more pronounced in DV.

Your cat is organic and the sharpness is great for detail, but non-organic objects such as metal or especially metal grills on cars where you compound the metalic shimer with line complications can drive you crazy.

What are your thoughts on that?

Thanks!
__________________
AM
Anthony Marotti is offline   Reply With Quote
Old August 14th, 2008, 07:42 AM   #105
Regular Crew

Join Date: Jan 2008
Location: Sweden
Posts: 41
Hey Anthony,

I will try that out, going out sometime soon again. I’m still learning so it will be interesting.

What I have noticed is that organic object, like faces, also often looks better when viewed on a broadcast monitor with lower detail settings, although this is assumptions. These below are with -2 in detail, and it also helps making the focus soften between prime focus and a bit of. With the viewfinder I find if often hard when fining proper focus with moving objects.

I'll post again with something non organic.
Attached Thumbnails
A tip on custom settings....-1.jpg   A tip on custom settings....-2.jpg

David Odell is offline   Reply
