Old February 3rd, 2008, 01:47 PM   #16
Trustee

Join Date: May 2005
Location: Allen, Texas U.S.A
Posts: 1,117
Mark,

That lens that come with it is a compromise that jvc did, to provide a CHEAP HD lens solution that is configured in a professional body.

That said, here is some important tips to get the most from that lens.
Dont use it at FULL OPEN, avoid if you can f2. And use f2.8 if you cant help it.
Doing so will exhibit lateral chromatic aberration. Do illustrate this, take your cam, point it at a bright plain wall, gray, white or off white. Throw your iris open, and youll notice the top half is different in color shade from the lower half. Slightly green and the other magenta.

DO NOT confuse this with the SSE that was prevalent in older models. That is a vertical split that has a defined line in the middle.
This lateral CA is graduated and subtle and is not a totally bad thing and has never gotten in the way of my work.

YOU MAY use this lens at wide open if the scene is totally cluterred and can "hide" this like leaves on a tree, look ata sample below, etc.

You dont need the HZ-CA13U unless you want to use th PL lenses. there are jvc lenses available for 1/3 inch like the 13x wide but they are expensive. I use mine with a DIY lens adapter that allows me to use both 35mm and 645 mid format lenses.
If you want a cheaper way to get wider shots you can use third party WA adapters. I retrofitted a 0.5x vitacon WA lens for DSLR to fit the fujinon thread and it works fine. See a post i did on that here
http://www.dvinfo.net/conf/showthread.php?t=102876

Heres some grabs you requested. The cave has gain setting, bit noisy but usable. The falls was in a dark ravine. Take note of my assistant standing on a rock at the bottom. Forget exact f stop but its wide open so note the top half of the waterfall is magenta, lower half is green. But still usable.

To show you that this baby is rugged theres a pic of me holding the cam "on the rocks" in the middle of river shooting the falls with my smiling key grip.

So order the camera already!

Ted
Attached Thumbnails
JVC HD-200 Pros/Cons?-whitewater2.jpg   JVC HD-200 Pros/Cons?-cave1.jpg

JVC HD-200 Pros/Cons?-falls-ravine.jpg   JVC HD-200 Pros/Cons?-rocks.jpg


Last edited by Ted Ramasola; February 3rd, 2008 at 01:49 PM. Reason: typo
Ted Ramasola is offline   Reply With Quote
Old February 3rd, 2008, 02:05 PM   #17
New Boot

Join Date: Nov 2007
Location: Las Vegas, NV
Posts: 17
Ted,

Thanks for the data on the lense and suggestions.

I may look into the camera with a HD lense instead of the one it comes with.
Any suggestions?

Nice pics by the way. Thanks for taking time to send them.

Mark
Mark Dalzell is offline   Reply With Quote
Old February 3rd, 2008, 02:36 PM   #18
Inner Circle

Join Date: Jan 2006
Posts: 2,290
Quote:
Originally Posted by Mark Dalzell View Post
Ted,

Thanks for the data on the lense and suggestions.

I may look into the camera with a HD lense instead of the one it comes with.
Any suggestions?

Nice pics by the way. Thanks for taking time to send them.

Mark
Try and find the 13x. I think you can get one for less than 5k in the used market.
Brian Luce is offline   Reply With Quote
Old February 3rd, 2008, 03:05 PM   #19
New Boot

Join Date: Nov 2007
Location: Las Vegas, NV
Posts: 17
Brian,

Do I need an adapter as well or does the 13x fit directly on to the HD-200?

Mark
Mark Dalzell is offline   Reply With Quote
Old February 3rd, 2008, 03:06 PM   #20
Major Player

Join Date: Aug 2006
Location: Larkspur, CA
Posts: 378
Quote:
Originally Posted by Mark Dalzell View Post
Justin,

Are you speaking about the current camera or an older model? The only reason I ask is I found this on the JVC site (which could be biased on their part also).

Newly-developed pixel converter
To enable 720p/60 recording, a new super encoder and a new pixel converter were developed, incorporating an adaptive filter which optimizes the scalar performance of cross-converted signals, including 1080i. The resultant effects are increased resolution and reduced aliasing. Objects thus have much more natural looking edges and images are therefore extremely lifelike in appearance.

If I'm correct, I plan on shooting 720/24p to get as close to a film look as possible. At this point and for me needs, the HD-200 is more appealing price wise than the 10K for the HD-250.

Mark
It's the same- all HD-200's are the same until they release another iteration.
Justin Ferar is offline   Reply With Quote
Old February 3rd, 2008, 09:07 PM   #21
Major Player

Join Date: Feb 2006
Location: Perth, Western Australia
Posts: 414
Agree with Sean

I 'm not overly impressed with the 50/60p. Not just the macro blocking, but you really have to also think about your NLE, I use Vegas, and JVC 50p at the moment is no good with Vegas, I basically have to export it as a 1080 50i avi, then bring it into DVD Architect to use it as a SD DVD, at 10Gb per minute it's a pain.
SDI was a clincher for me. As Sean mentioned the convergent design will help give you a similar image from a camera worth $10,000 more. Also you can capture SDI into your NLE via a SDI card and use SDI monitoring with a on camera monitor.
But if you really don't forsee such needs, then the 200 is more than fine, and everything is at a pricepoint which is obvious, but it's now almost the same price for 250 as it was for the 200 when they first came out.

edit: sorry I meant Justin, I was thinking Sean Adair for some reason :-P

Adam

Last edited by Adam Letch; February 3rd, 2008 at 10:06 PM.
Adam Letch is offline   Reply With Quote
Old February 3rd, 2008, 09:08 PM   #22
Major Player

Join Date: May 2005
Location: Portugal
Posts: 282
Quote:
Originally Posted by Mark Dalzell View Post
Diogo, please excuse my ignorance but can you elaborate a bit more on the SSE? I assume your referring to the "split screen" feature. Has this been eliminated in the HD-200 or fixed or ? Good/Bad.
Mark
Sorry, we're so used to talk about SSE here that I didn't think you probably don't know what it means. SSE means Split Screen Efect and it has been fixed on 200 series. You can hardly see SSE on 100 series under certain low light situations, but not on the 200 because these have a better compensation process and can completely eliminate the efect. I have both HD100 and HD200 and the second one is much better in many ways, no SSE, better image quality, better performance in low light, software compensation for chromatic aberrations... buy it, it's an excelent camera.
Diogo Athouguia is offline   Reply With Quote
Old February 3rd, 2008, 10:55 PM   #23
Trustee

Join Date: May 2005
Location: Allen, Texas U.S.A
Posts: 1,117
And for editing the footage from hdxx without problems in any frame rate I recommend the robust program from grass valley/canopus- EDIUS PRO.

60P is beautiful. Drop it into the timeline, conform to either 24 or 30 fps and youve got beautiful slow motion.

Very stable on an XP pro sp2 system.

Our facility used Premiere for more than 10 years but abandoned it when they started the prem Pro series. For around 4 - 5 years we have 5 edit suites in our facility running them. Theyre reliable.

Vegas is a new comer. Im not a sony software fan, this came out as a software only solution for small home users to startup outfits, since the others are usually optimized with hardware.

Premiere pro is now too resource heavy, but other adobe products we use intensively, like after effects, and photoshop.

FCP is , well, a mac. I'm an IT guy, I dont like somethin I can't open the hood tweak the engine.

Ted
Ted Ramasola is offline   Reply With Quote
Old February 4th, 2008, 10:27 AM   #24
New Boot

Join Date: Nov 2007
Location: Las Vegas, NV
Posts: 17
Adam,

For my NLE I use Vegas Pro 8. I had a new PC configured a few months back with dual quad Zeons, 4 Gb Ram a
Matrox Parhelia graphics card and plenty of HD's and 2 of which are WD Raptors 150Gb, XP Pro, SP3.

My question is, will I have issues with Vegas Pro 8 when I go to import my footage which I will probably being shooting at 720/24p?

Diogo, thanks for clarifying the SSE question. Doesn't seem to be an issue anymore.

Mark
Mark Dalzell is offline   Reply With Quote
Old February 4th, 2008, 02:58 PM   #25
Major Player

Join Date: Feb 2006
Location: Perth, Western Australia
Posts: 414
Hey Mark

Vegas works perfectly for 24/25/30p, I can edit in 50p, but if you render out at 50p, it the image has multiple ghosting like your shooting at a real slow fps? Anyway, Edius and FCP now natively support it, so hopefully maybe in the next build Sony will address it.

Regards

Adam
Adam Letch is offline   Reply With Quote
Old February 9th, 2008, 08:48 PM   #26
New Boot

Join Date: Dec 2007
Location: Niwot, CO
Posts: 8
Right Camera for birds in flight?

Gentlemen,

This seems to be the right place to get some knowledgeable advice. I've owned the Canon XLH1 for about a year. I like it....however there seems to be some motion blur when tracking fast moving birds. I'm being encouraged to go with the JVC HD GY-250 with the Canon 20X KT20x5B-KRS, the high definition zoom lens for 1/3" CCD video cameras because shooting in 60P vs interlaced will significantly improve the quality of my slow motion footage, which I use alot in my bird videos.

Do you guys agree with this analysis? I'm also concerned about getting the magnification I need with the 20X. With the Canon XL H1 I sometimes use a cheap Canon EOS 100mmm-300mm photo lens.

One thing that has me concerned is won't shooting in 720 cause some reduction in resolution when viewed on a 1080 P HD Monitor?
John Vanderpoel is offline   Reply With Quote
Old February 10th, 2008, 06:35 PM   #27
Major Player

Join Date: May 2005
Location: Portugal
Posts: 282
John, if you use a lot of slo-mos than 60p is the right choice for you. You can find some slow motion clips from 60p footage on this forum, I think Tim Dashwood posted some examples.

Besides that, if you like working with an H1 you'll love this camera. It's much more user friendly.

Last edited by Diogo Athouguia; February 11th, 2008 at 03:13 PM.
Diogo Athouguia is offline   Reply With Quote
Old February 11th, 2008, 08:28 AM   #28
New Boot

Join Date: Dec 2007
Location: Niwot, CO
Posts: 8
60P slow motion

Thanks Diogo...I'll look at the examples you referenced
John Vanderpoel is offline   Reply With Quote
Old May 16th, 2008, 10:29 AM   #29
New Boot

Join Date: Apr 2006
Location: Baton Rouge, LA
Posts: 11
We've only had our HD-200 for a couple of months and the SSE is worse than our HD-100.

The whole reason we bought a 200 was because we were told that the SSE was eliminated. Well guess what, it wasn't.
Dwayne Dupre is offline   Reply With Quote
Old May 16th, 2008, 10:37 AM   #30
Inner Circle

Join Date: Sep 2002
Location: Vancouver, British Columbia (formerly Winnipeg, Manitoba) Canada
Posts: 4,087
Quote:
Originally Posted by Ted Ramasola View Post
Mark,

That lens that come with it is a compromise that jvc did, to provide a CHEAP HD lens solution that is configured in a professional body.

That said, here is some important tips to get the most from that lens.
Dont use it at FULL OPEN, avoid if you can f2. And use f2.8 if you cant help it.
Doing so will exhibit lateral chromatic aberration. Do illustrate this, take your cam, point it at a bright plain wall, gray, white or off white. Throw your iris open, and youll notice the top half is different in color shade from the lower half. Slightly green and the other magenta.

Ted
According to Tim Dashwood's DVD on ProHD, the top and bottom CA can be adjusted to compensate for the CA inherent in each lens by adjusting the green setting. My 200 shipped with proper adjustment for the stock lens so I haven't had to make this adjustment.

I still see the green and magenta feathered edges on highlight areas when wide open and full telephoto, but that is a lens issue. Until I can afford a replacement lens, I'll just try to avoid wide open telephoto work.
__________________
Shaun C. Roemich Road Dog Media - Vancouver, BC - Videographer - Webcaster
www.roaddogmedia.ca Blog: http://roaddogmedia.wordpress.com/
Shaun Roemich is offline   Reply
