Old December 21st, 2013, 03:40 AM   #1
Major Player

Join Date: Apr 2008
Location: Sydney Australia
Posts: 899
Sony SELP18-105G dissapointing!

Just tried out the new Sony SELP 18-105 G F4.0:1 lens on the FS700...

The lens works well in as much as it doesn't lose focus and 'jink' on the long end when you zoom back like the earlier 18-200. Auto focus, auto iris, stabilisation etc, etc all works well, quite well in fact (note: it doesn't have the video mode 'active' stabilisation of the 18-200. Only 'off' and 'standard'.) The power zoom is much quicker than the SELP 18-200. About three seconds end to end when camera menu set to variable. Strange thing is if you use a Varizoom zoom demand it's about 30% quicker again. About two seconds end to end

The BIG downer is the pronounced pincushion effect on full zoom. In fact it looks like it may have slight barrel distortion at the wide end. This you might just get away with but the pincushion on the long end means I won't be buying it. I believe, though haven't tried yet, is that on an NEX still camera with latest firmware it's not an issue as the still cameras have inbuilt software correction for these anomalies. Sadly no correction for the video camera end of the family.

Have attached a still of the long end pincusion. Didn't worry about the wide end as I felt that was pretty minimal barrel distortion but the long end, phew!

Chris Young
CYV Productions
Sydney.
Attached Thumbnails
Sony SELP18-105G dissapointing!-18-105-pincushion-zoom.jpg
Christopher Young is offline   Reply With Quote
Old December 21st, 2013, 10:02 AM   #2
Major Player

Join Date: Apr 2010
Location: NJ/NYC
Posts: 560
Re: Sony SELP18-105G dissapointing!

shame, as it's an interesting lens.

have you tried any post correction? in premiere using the lens distortion effect with some negative numbers can do some nice correction, and it's keyframable, so you could have it actively correct a zoom.

post a sample clip if you like and i'll correct it
__________________
C100 - GH4 - NYC Shooter
www.DarrenLevine.com
Darren Levine is offline   Reply With Quote
Old December 21st, 2013, 07:34 PM   #3
Major Player

Join Date: Apr 2008
Location: Sydney Australia
Posts: 899
Re: Sony SELP18-105G dissapointing!

Yes its correctable but would you want to correct every shot on a multicam two hour show? The time required alone to correct a single zoom shot let alone dozens and dozens of them that go from mild barrel distortion to pincushion would be totally unrealistic IMHO.

Will be interesting to see if Sony can come up with a firmware solution.

Chris Young
Sydney

Last edited by Christopher Young; December 21st, 2013 at 07:34 PM. Reason: Doh! typo
Christopher Young is offline   Reply With Quote
Old December 22nd, 2013, 10:19 PM   #4
Major Player

Join Date: Mar 2007
Location: Salem, Oregon
Posts: 409
Re: Sony SELP18-105G dissapointing!

I won't post a link, but a very spirited and informative thread on another site absolutely lambastes this lens. It was never meant for the FS series of video cameras, though Sony evidently has not made that tidbit apparent. Thank goodness I read the scathing reviews of early buyers: I was just about to pull the trigger.
__________________
www.CinemActionFilms.com
Steven Reid is offline   Reply With Quote
Old December 23rd, 2013, 02:47 AM   #5
Regular Crew

Join Date: Apr 2013
Location: Duisburg
Posts: 93
Re: Sony SELP18-105G dissapointing!

There will hardly be any firmware to integrate in camera correction of lenses.

All the other NEX cameras but the FS100/700 use photo sensors and "squeeze" the video signal out of the megapixels. This alone is enough room for the correction.

The FS100/700 use dedicated video sensors and don't hve that extra megapixels and processor, that can handle this kind of operation.
Erik Wittbusch is offline   Reply With Quote
Old December 23rd, 2013, 11:48 AM   #6
Major Player

Join Date: Jul 2002
Location: Juneau, AK
Posts: 818
Re: Sony SELP18-105G dissapointing!

The FS100 and 700 do not have the same sensor. The FS100 has 2.2 MP and the FS700 has a lot
more. I know the FS700 shoots 8 MP stills so at least that or more on its sensor. Might that be
enough for firmware correction? I dunno but the two cameras have very different sensors.....
Gabe Strong is offline   Reply With Quote
Old December 24th, 2013, 05:34 AM   #7
Regular Crew

Join Date: Apr 2013
Location: Duisburg
Posts: 93
Re: Sony SELP18-105G dissapointing!

The sensors are different, but not that much.
Both are dedicated video sensors which have a full pixel readout
at 1080 (FS100) or 4k (FS700). One can say, that they use a
similar way of processing the resolution in contrary to the
VG and EA50 cameras, which use line skipping/pixel binning.
Erik Wittbusch is offline   Reply With Quote
Old December 24th, 2013, 08:29 AM   #8
Inner Circle

Join Date: Dec 2005
Location: Bracknell, Berkshire, UK
Posts: 4,957
Re: Sony SELP18-105G dissapointing!

The FS700 is a 4K sensor with a primary active area that is 17:9. The FS100 has approx 2.3K pixels in a 16:9 active area.

Both sensors, but particularly the FS700 sensors have a lot of unused or at least "non active" pixels. The FS700 sensor is 11MP with only about 8.8MP "active". So there are a lot of spare pixels. Some of these are used for black balance and noise compensation but when you use the cameras active stabilisation there is no change to the image size or resolution, so there must be extra pixels around the main active area that are used as part of the stabilisation process. These could be used for image correction, but the bigger issue is that this would have to be done in real time and at up to 60fps, so some serious number crunching and power requirements.
__________________
Alister Chapman, Film-Maker/Stormchaser http://www.xdcam-user.com/alisters-blog/ My XDCAM site and blog. http://www.hurricane-rig.com
Alister Chapman is offline   Reply With Quote
Old December 28th, 2013, 01:29 AM   #9
Regular Crew

Join Date: Nov 2006
Location: San Jose, CA
Posts: 144
Re: Sony SELP18-105G dissapointing!

I had this lens for a couple of days before sending it back due to the terrible distortion. Spoke to Sony and they said that a fix may happen, but it would not come before spring. Bummer.
__________________
www.elkinseye.com
David Elkins is offline   Reply With Quote
Old December 29th, 2013, 02:08 AM   #10
Major Player

Join Date: Apr 2008
Location: Boston
Posts: 496
Re: Sony SELP18-105G dissapointing!

Wow, how does a company with a name and rep like Sony send out such garbage.
__________________
Dave -
Dave Allen is offline   Reply With Quote
Old December 30th, 2013, 10:16 PM   #11
Major Player

Join Date: Apr 2008
Location: Sydney Australia
Posts: 899
Re: Sony SELP18-105G dissapointing!

Quote:
there must be extra pixels around the main active area that are used as part of the stabilisation process. These could be used for image correction, but the bigger issue is that this would have to be done in real time and at up to 60fps, so some serious number crunching and power requirements.
I have seen 50p AVC HD footage shot on the Sony NEX 6 with this 18-105 lens and it manages the correction in real time so Sony can do it. No issues on the NEX 6, the verticals at full zoom are straight. I guess it's whether Sony feel they will sell enough lenses to the FS100/700 brigade to justify a firmware fix.

Chris Young
Sydney
Christopher Young is offline   Reply With Quote
Old December 31st, 2013, 06:14 AM   #12
Austinite

Join Date: Sep 2013
Location: Austin
Posts: 537
Re: Sony SELP18-105G dissapointing!

Hmmm. G lens...
Phil Goetz is offline   Reply With Quote
Old February 1st, 2014, 01:59 PM   #13
Trustee

Join Date: Oct 2002
Location: Phoenix, AZ
Posts: 1,677
Re: Sony SELP18-105G dissapointing!

Phil, your point?

According to Sony "In the α lens lineup at Sony, G Lenses stand shoulder to shoulder with the outstanding Carl Zeiss optics."

Link here: G Lenses – Concepts behind the "G"

If you are saying what I think your are I agree. This is not a Zeiss class lens, but Sony claims it is. Look how Sony defines them. If one was to see this Sony page first why would he ever think for one Second that ANY G series lens would not work well on his FS700. Especially when you are going Sony to Sony in the native mount. Is that what it has come to now? Native compatibly can no longer be assumed. When doing our purchase research we must also check "known product compatibility lists" for everything? If Sony is going to market it as a high end lens but knows it will not work with a high end camera with that mount it should be made more clear than it is.

Steve
__________________
www.CorporateShow.com
Been at this so long I'm rounding my years of experience down...not up!

Last edited by Steven Digges; February 1st, 2014 at 02:01 PM. Reason: typo
Steven Digges is offline   Reply With Quote
Old February 2nd, 2014, 02:24 AM   #14
Major Player

Join Date: Jul 2002
Location: Juneau, AK
Posts: 818
Re: Sony SELP18-105G dissapointing!

Yup, that's why I bought it. G branded lens? Perfect for the FS700!
Yeah I didn't check the compatibility, just assuming it would be a high
quality lens.
Gabe Strong is offline   Reply
