Old March 27th, 2008, 10:08 AM   #16
Trustee

Join Date: Apr 2005
Posts: 1,268
Quote:
Originally Posted by Piotr Wozniacki View Post
My experience is that underexposing you can get away with provided you crush (compress) blacks; otherwise the noise will hit - even without using gain.
That's exactly my experience too and I'm starting to wonder if this is the best the camera can perform with shadows? Either no detail in the shadows or noise.
Michael Maier is offline   Reply With Quote
Old March 27th, 2008, 10:11 AM   #17

Join Date: Nov 2001
Location: santa fe, nm
Posts: 3,264
Images: 10
Obviously, this won't work with night scenes.
Interesting comment from Piotr. Really haven't played much with crushing shadows. I don't shoot, much, in very low light and have no experience with it and the EX1.
Bill Ravens is offline   Reply With Quote
Old March 27th, 2008, 10:32 AM   #18
Regular Crew

Join Date: Jan 2008
Location: Haiku, HI
Posts: 196
Images: 12
Quote:
Originally Posted by Bill Ravens View Post
Obviously, this won't work with night scenes.
Interesting comment from Piotr. Really haven't played much with crushing shadows. I don't shoot, much, in very low light and have no experience with it and the EX1.
This is it exactly. The curves are all amplifying (stretching) the lower quartile values. The more of the scene that registers there and the darker it is, the more this amplification will show noise, unless the curve is flattened and or compessed. It is all a matter of amplifying darks.
Randy Strome is offline   Reply With Quote
Old March 27th, 2008, 10:36 AM   #19
Trustee

Join Date: Apr 2005
Posts: 1,268
Quote:
Originally Posted by Randy Strome View Post
This is it exactly. The curves are all amplifying (stretching) the lower quartile values. The more of the scene that registers there and the darker it is, the more this amplification will show noise, unless the curve is flattened and or compessed. It is all a matter of amplifying darks.
Could you explain it in layman's terms?

Thanks.
Michael Maier is offline   Reply With Quote
Old March 27th, 2008, 11:00 AM   #20

Join Date: Nov 2001
Location: santa fe, nm
Posts: 3,264
Images: 10
Randy's not making much sense to me. Seems like any dark scene will have a gradation from crushed black up into grey. Somewhere in there, there's gonna be some real ugly noise. I don't like the low light noise on the EX1. It's almast as bad as my HD110.
Bill Ravens is offline   Reply With Quote
Old March 27th, 2008, 11:13 AM   #21
Trustee

Join Date: Apr 2005
Posts: 1,268
Quote:
Originally Posted by Bill Ravens View Post
Randy's not making much sense to me. Seems like any dark scene will have a gradation from crushed black up into grey. Somewhere in there, there's gonna be some real ugly noise. I don't like the low light noise on the EX1. It's almast as bad as my HD110.
Well, yes but surely not as bad as the HVX200 or HV20.
Michael Maier is offline   Reply With Quote
Old March 27th, 2008, 11:27 AM   #22

Join Date: Nov 2001
Location: santa fe, nm
Posts: 3,264
Images: 10
It's just the nature of the 4:2:0 MPEG2 codec. Not much to do with it.
Bill Ravens is offline   Reply With Quote
Old March 27th, 2008, 11:51 AM   #23
Trustee

Join Date: Apr 2005
Posts: 1,268
Quote:
Originally Posted by Bill Ravens View Post
It's just the nature of the 4:2:0 MPEG2 codec. Not much to do with it.
Well, the HVX200 is supposedly 4:2:2 but it's worse in noise and low light.
Michael Maier is offline   Reply With Quote
Old March 27th, 2008, 12:41 PM   #24
Inner Circle

Join Date: Aug 2006
Location: Poland
Posts: 4,086
OK, perhaps these are too extreme to illustrate what I mean, but which one do you like better?

And yes - Bill is right that on the gray scale, even with the darkest areas crushed down to the floor along with any noise, the noise will appear elsewhere - but somehow I still prefer the crushed one for its "Nighty" look.
Attached Thumbnails
How many stops under can you get away with?-image79.jpg   How many stops under can you get away with?-image78.jpg

__________________
Sony PXW-FS7 | DaVinci Resolve Studio; Magix Vegas Pro; i7-5960X CPU; 64 GB RAM; 2x GTX 1080 8GB GPU; Decklink 4K Extreme 12G; 4x 3TB WD Black in RAID 0; 1TB M.2 NVMe cache drive
Piotr Wozniacki is offline   Reply With Quote
Old March 27th, 2008, 01:54 PM   #25
Regular Crew

Join Date: Jan 2008
Location: Haiku, HI
Posts: 196
Images: 12
Quote:
Originally Posted by Piotr Wozniacki View Post
OK, perhaps these are too extreme to illustrate what I mean, but which one do you like better?

And yes - Bill is right that on the gray scale, even with the darkest areas crushed down to the floor along with any noise, the noise will appear elsewhere - but somehow I still prefer the crushed one for its "Nighty" look.
Hi guys,

What are your settings here? What gain and what gamma (curve)? If the curve is modified by other PP settings, please let me know. I am typically shooting towards the right, but this has me wainting to do some tests.

Also, Piotr, did you have sharpening on in these shots? Pretty heavy halos are present around the couch. Sharpening off is pretty well a must where noise is an issue, as you end up sharpening the noise.
Randy Strome is offline   Reply With Quote
Old March 28th, 2008, 10:32 AM   #26
New Boot

Join Date: Jan 2008
Location: Baton Rouge Louisiana
Posts: 14
Underexposing never produces noise for me. If anything it helps (at least 1 to 1 and 1/2 stops)...its only the overexposing that does it. I'm shooting a really pretentious artsy fartsy black and white short and underexposing by 2/10ths of a stop to really enhance the chiaroscuro lighting by adding contrast and it looks better than a contrast filter added in post:D
Chris Aaron is offline   Reply With Quote
Old March 28th, 2008, 02:23 PM   #27
Regular Crew

Join Date: Jan 2008
Location: Haiku, HI
Posts: 196
Images: 12
Quote:
Originally Posted by Chris Aaron View Post
Underexposing never produces noise for me. If anything it helps (at least 1 to 1 and 1/2 stops)...its only the overexposing that does it. I'm shooting a really pretentious artsy fartsy black and white short and underexposing by 2/10ths of a stop to really enhance the chiaroscuro lighting by adding contrast and it looks better than a contrast filter added in post:D
My few early experiments there were the same. Also, helpful to reduce black gamma (which should really be called lower value gamma) and will help to reduce noise which is more apparent in the lower values. I haven't tested below 1.5 stops down, but you will not likely need to go that low to achieve a low key look if you back off the black gamma (which is actually pretty pumped up by default).
Randy Strome is offline   Reply With Quote
Old May 7th, 2008, 03:39 AM   #28
Trustee

Join Date: Apr 2005
Posts: 1,268
Quote:
Originally Posted by Eric Pascarelli View Post
If you are using a spot meter, you are probably asking more about latitude that over/under exposure. You can probably go about 4 to 5 stops under mid grey in your spot readings before the metered areas disappear in the noise floor.
Hi guys. I'm revisiting this subject at the moment and was wondering if you all agree with Eric here. 4 to 5 stops under 18% grey is all one should go in order to avoid noise? Or will this also depend on the type of gamma selected (cine, std etc)?
It's interesting to note that the RED ONE also has the same bottom of 5 stops under 18% grey before noise kicks in really bad.
Michael Maier is offline   Reply With Quote
Old May 7th, 2008, 11:42 AM   #29
Regular Crew

Join Date: Nov 2006
Location: Worcester. United Kingdom
Posts: 197
Quote:
Originally Posted by Piotr Wozniacki View Post
OK, perhaps these are too extreme to illustrate what I mean, but which one do you like better?
Thanks for posting those images Piotr.
I'm a little worried about the halos too, but the one on the right looks much nicer than the one on the left.

What I don't understand is why everyone's hellbent on producing the "film look" in camera when there's so much fabulous image and colour control available in post these days.

I prefer to shoot correctly exposed footage whenever possible and crush the blacks or whatever else I want to do in post. That way I keep my options open with the original footage.

Crush your blacks, or blow your highlights in camera, and you're stuck with it forever. Where there's no detail, there's no detail but correctly expose in the first place and you can have fun as long as you retain the originals.

Enlighten me someone!
__________________
I taught you all I know and still you know nothing.
Andy Nickless is offline   Reply With Quote
Old May 7th, 2008, 12:40 PM   #30
Inner Circle

Join Date: Feb 2004
Location: Brooklyn, NY, USA
Posts: 3,777
Andy I'm with you on this. My main concern when shooting is not blowing highlights because you can't retrieve those in post.

Getting the widest dynamic range is important to maximum flexibility in post.

Of course there certainly is good reason to paint as much as possible in camera too. Some DPs want to have as much control of the source they hand to the post people. Sometimes they deliberately want to limit their options. Sometimes one might feel in camera processing can avoid issues that might happen when processing in post.

That said, I'd like to have maximum options in post.

It is nice that with the EX1 we have choice though. Tailor to your workflow. That's flexible!
Craig Seeman is offline   Reply
