Old April 21st, 2008, 04:00 PM   #46
Major Player

Join Date: Dec 2007
Location: Hertfordshire UK
Posts: 414
A couple more

http://www.freewebs.com/markwilliams/Mark3.png

http://www.freewebs.com/markwilliams/Mark4.png

What do people think of these? Images good to go as are?
Mark David Williams is offline   Reply With Quote
Old July 16th, 2009, 05:22 PM   #47
Regular Crew

Join Date: Apr 2008
Location: Torres, Brazil
Posts: 115
CA can be corrected in any software i believe.

in vegas, i triplicate the track, using color curves, let only a single color per track
put track in "ADD" mode, and you can resize the channels independently, fixing CA.

so, i let this project to fix CA. drag, and export. can use keyframes also to adjust based on zoom.

Oliver Neubert example:
Attached Thumbnails
Chromatic aberration-test-reg-01bc.jpg   Chromatic aberration-ca.jpg

Marlon Martins is offline   Reply With Quote
Old July 17th, 2009, 01:17 AM   #48
Major Player

Join Date: Jun 2006
Location: Studio Alnitak, Melbourne, Victoria, Australia
Posts: 640
Images: 3
very interesting.
Serena Steuart is offline   Reply With Quote
Old July 17th, 2009, 04:09 AM   #49
Inner Circle

Join Date: Aug 2006
Location: Poland
Posts: 4,086
As a Vegas user, I find it VERY interesting indeed.

Marlon, could you please elaborate on how exactly you "resize the channels independently" - do you use Track Motion? I'd suspect moving one single-color track relative to another could remove the CA in one place (say at the frame extremities), but introduce color shift in another (like the frame center)...

But I'm certainly missing something!

PS Perhaps you could share your example .veg file used to achieve this?
__________________
Sony PXW-FS7 | DaVinci Resolve Studio; Magix Vegas Pro; i7-5960X CPU; 64 GB RAM; 2x GTX 1080 8GB GPU; Decklink 4K Extreme 12G; 4x 3TB WD Black in RAID 0; 1TB M.2 NVMe cache drive

Last edited by Piotr Wozniacki; July 17th, 2009 at 05:47 AM.
Piotr Wozniacki is offline   Reply With Quote
Old July 17th, 2009, 04:33 PM   #50
Regular Crew

Join Date: Apr 2008
Location: Torres, Brazil
Posts: 115
yes, i use track motion, with curves filters on track also.

of course, there other ways, other filters, better workflow. but this is my first try, i just got a ex3 about a week. testing now with shneider fisheye ;)

here is the project as example. values are crude, to be perfect need more samples and tests.
Attached Files
File Type: zip CA.zip (501.8 KB, 79 views)
Marlon Martins is offline   Reply With Quote
Old July 17th, 2009, 07:21 PM   #51
Trustee

Join Date: Nov 2005
Location: Sydney Australia
Posts: 1,570
Here's another approach shamelessly borrowed from an AE tutorial elsewhere. Not without its pitfalls. The white dot is simply so I could tell how much desaturation was being done as I previewed the result at full raster.

Looking at the frame grab this doesn't look like classical CA, the amount of fringing seems too constant over the frame.
Attached Files
File Type: zip CA-SecondaryCC.zip (501.6 KB, 54 views)
Bob Grant is offline   Reply With Quote
Old July 17th, 2009, 08:31 PM   #52
Regular Crew

Join Date: Mar 2004
Location: NY
Posts: 186
Quote:
Originally Posted by Marlon Martins View Post
yes, i use track motion, with curves filters on track also.

of course, there other ways, other filters, better workflow. but this is my first try, i just got a ex3 about a week. testing now with shneider fisheye ;)

here is the project as example. values are crude, to be perfect need more samples and tests.
Hi Marlon, could you check if you get vignetting with your Fisheye please?
Max Allen is offline   Reply With Quote
Old July 18th, 2009, 07:55 AM   #53
Inner Circle

Join Date: Mar 2003
Location: Billericay, England UK
Posts: 4,711
Quote:
Originally Posted by Max Allen View Post
could you check if you get vignetting with your Fisheye?
Er - the whole point of a fisheye lens is to place a circular 180 degree image within the rectangular gate. Now that's vignetting.

Full frame fisheyes on the other hand shouldn't obviously vignette.
Tom Hardwick is offline   Reply With Quote
Old July 19th, 2009, 03:41 AM   #54
Inner Circle

Join Date: Aug 2006
Location: Poland
Posts: 4,086
Quote:
Originally Posted by Bob Grant View Post
Looking at the frame grab this doesn't look like classical CA, the amount of fringing seems too constant over the frame.
Exactly - and this is why Marlon's method of moving the soloed red channel in relation to the other 2 channels over entire frame, actually works here!

In the case of typical CA, where it mainly shows at frame extremities, your method of adjusting color locally is more adequate - though tedious.
__________________
Sony PXW-FS7 | DaVinci Resolve Studio; Magix Vegas Pro; i7-5960X CPU; 64 GB RAM; 2x GTX 1080 8GB GPU; Decklink 4K Extreme 12G; 4x 3TB WD Black in RAID 0; 1TB M.2 NVMe cache drive
Piotr Wozniacki is offline   Reply With Quote
Old July 19th, 2009, 03:51 AM   #55
Regular Crew

Join Date: Mar 2004
Location: NY
Posts: 186
Quote:
Originally Posted by Tom Hardwick View Post
Er - the whole point of a fisheye lens is to place a circular 180 degree image within the rectangular gate. Now that's vignetting.

Full frame fisheyes on the other hand shouldn't obviously vignette.
Isn't the Century/Schneider full frame?
Max Allen is offline   Reply With Quote
Old July 19th, 2009, 06:14 AM   #56
Regular Crew

Join Date: Nov 2008
Location: UK
Posts: 174
I came across this video tutorial, but only for after effects - are there similar controls in Vegas ?

Removing Chromatic Aberration : Adobe After Effects Video Tutorial
Dave Tyrer is offline   Reply With Quote
Old July 21st, 2009, 04:24 PM   #57
Regular Crew

Join Date: Apr 2008
Location: Torres, Brazil
Posts: 115
Quote:
Originally Posted by Max Allen View Post
Hi Marlon, could you check if you get vignetting with your Fisheye please?
sure ;)

vignetting is very low, normally not perceptible.

a quick test:
Attached Thumbnails
Chromatic aberration-vig_fisheye.jpg
Marlon Martins is offline   Reply With Quote
Old July 22nd, 2009, 09:31 AM   #58
Trustee

Join Date: Nov 2005
Location: Sydney Australia
Posts: 1,570
Quote:
Originally Posted by Dave Tyrer View Post
I came across this video tutorial, but only for after effects - are there similar controls in Vegas ?

Removing Chromatic Aberration : Adobe After Effects Video Tutorial
Yes. See the sample project file I uploaded above.
I used the Secondary Color Corrector to select the color of the fringe and to desaturate that color. As the tutorial also shows this can easily fail if the same color appears in other parts of the frame. Then you have to use a mask as well. That can become very tedious if you need to keyframe the mask as well.
Bob Grant is offline   Reply
