Old June 13th, 2008, 01:42 PM   #1
New Boot

Join Date: Mar 2008
Location: Auckland, New Zealand
Posts: 24
White Balance on EX1 with ExpoDisc

Hello
Has anyone tried using the ExpoDisc for White Balance setting on the EX1.
I can not find any references to it in a search.
If you have, what are your impressions of it? Is it a good option?
Malcolm
Malcolm Dyer is offline   Reply With Quote
Old June 13th, 2008, 02:07 PM   #2
Inner Circle

Join Date: Feb 2004
Location: Brooklyn, NY, USA
Posts: 3,778
Interesting product
http://www.expoimaging.net/products/...lter_-_Neutral

I'm not sure I trust using a white balance filter.

I use Vortex Warm Cards. Same folks who make the EX training DVD many of us have purchased.

http://www.warmcards.com/
You can get them from B&H as well as order on the above site.
Craig Seeman is offline   Reply With Quote
Old June 13th, 2008, 02:10 PM   #3
Inner Circle

Join Date: Feb 2004
Location: Brooklyn, NY, USA
Posts: 3,778
My concern about such filter is that one would want to place a balance card in the area you're targeting rather than directly in front of the lens to get the correct color temperature.
Craig Seeman is offline   Reply With Quote
Old June 13th, 2008, 02:28 PM   #4
Regular Crew

Join Date: Aug 2003
Location: Atlanta, GA
Posts: 126
The Expo disk works great for my still work. I've used it for a couple of years. Haven't tried it for video but I would assume it would work the same. Same principle after all.
Rick Jones is offline   Reply With Quote
Old June 13th, 2008, 02:39 PM   #5
Inner Circle

Join Date: Feb 2004
Location: Brooklyn, NY, USA
Posts: 3,778
B&H does carry it.
http://www.bhphotovideo.com/c/produc...tal_White.html
Craig Seeman is offline   Reply With Quote
Old June 13th, 2008, 02:49 PM   #6
Inner Circle

Join Date: Jun 2003
Location: San Jose, CA
Posts: 2,222
I prefer the WhiBal card for my still work, and that has spilled over to my video work.
The ExpoDisc makes more sense when you are on the move and need to white balance often and quickly. If your camera is stationary, you won't be able to take the ExpoDisc reading by revsersing yourself at the source. More often than not, it is difficult to deal with local color casts (water, sand) with an ExpoDisc. You can just place the card at the level needed and zoom in to white balance to that. Granted, often it is sometimes difficult to get the full light source on the WhiBal card when objects are casting shadows.
Gints Klimanis is offline   Reply With Quote
Old June 13th, 2008, 04:13 PM   #7
Regular Crew

Join Date: Feb 2008
Location: Tuscaloosa, Alabama
Posts: 69
I keep a white card hanging on my tripod for quick white balances when moving between different lights.
I find I would prefer to warm-up a shot with the 3-way color corrector in FCP.

kj
Kevin Wayne Jones is offline   Reply With Quote
Old June 13th, 2008, 07:33 PM   #8
Regular Crew

Join Date: Nov 2004
Posts: 1,414
heard you can use a paper coffee filter that will work the same way???
Ray Bell is offline   Reply With Quote
Old June 13th, 2008, 09:33 PM   #9
Inner Circle

Join Date: Jun 2003
Location: San Jose, CA
Posts: 2,222
Quote:
Originally Posted by Ray Bell View Post
heard you can use a paper coffee filter that will work the same way???
The point of buying a product is that it is manufactured to be spectrally neutral. All you have to do is leave a paper product in the sun for a few hours to watch it yellow. Though, a slightly off-color paper product is better than nothing.
Gints Klimanis is offline   Reply With Quote
Old June 13th, 2008, 10:31 PM   #10
Regular Crew

Join Date: Aug 2003
Location: Atlanta, GA
Posts: 126
Yeah, when the Expodisc first came out people were trying to see if Pringles tops and other tops like it would work the same. The results were across the board with some working well and others less than so. At least my Expodisc hasn't become yellow over time!
Rick Jones is offline   Reply With Quote
Old June 14th, 2008, 02:45 PM   #11
New Boot

Join Date: Mar 2008
Location: Auckland, New Zealand
Posts: 24
Thank you for the comments.
I can see pointing the camera at the light source could be a problem especially if it is not in the immediate field of view.
Malcolm
Malcolm Dyer is offline   Reply With Quote
Old June 14th, 2008, 03:59 PM   #12
Inner Circle

Join Date: Jun 2003
Location: San Jose, CA
Posts: 2,222
Quote:
Originally Posted by Malcolm Dyer View Post
Thank you for the comments.
I can see pointing the camera at the light source could be a problem especially if it is not in the immediate field of view.
Malcolm
Chuckle. In those situations, you can mount the Expodisc and point it at a white card.
Gints Klimanis is offline   Reply With Quote
Old June 14th, 2008, 07:50 PM   #13
New Boot

Join Date: Mar 2008
Location: Auckland, New Zealand
Posts: 24
Hello Gints
I have considered that but it seemed a bit of a belt and braces approach.
There are times when the incident light does not fall near the camera to do that.
Another factor is constant removal and replacement of the sun shade to clip it on.
I might get one anyway to experiment with.
Malcolm
Malcolm Dyer is offline   Reply With Quote
Old June 14th, 2008, 09:44 PM   #14
Regular Crew

Join Date: Nov 2004
Posts: 1,414
removed by poster

Last edited by Ray Bell; June 15th, 2008 at 08:29 AM.
Ray Bell is offline   Reply With Quote
Old June 18th, 2008, 01:32 PM   #15
Regular Crew

Join Date: Oct 2006
Location: Vancouver, Canada
Posts: 173
After reading this article, I picked one up today. And I couldn't be any happier with the results!
It nice to have it help with exposure, but white balance is the thing I'm fighting all the time with this camera. And to have something like this and not have to worry about setting up a card all the time, it's great! I will probably start using this on all my shoots!

In the pictures I've posted, #1 is with auto white balance and auto exposure. In #2 I've set the WB & the exposure with the expodisc.
Attached Thumbnails
White Balance on EX1 with ExpoDisc-1-auto.png   White Balance on EX1 with ExpoDisc-2-expodisc.png

__________________
Justin
http://www.carlsonmedia.ca
Justin Carlson is offline   Reply
