Old November 30th, 2008, 10:14 PM   #16
Major Player

Join Date: May 2008
Location: Nuremberg, Germany
Posts: 285
Quote:
Originally Posted by Alex Raskin View Post
Are you saying that EX1 derives 720p from 1080p by applying 6dB gain, then sizing down and blurring the image?
Exactly. The blurring must be done before downscaling to avoid aliasing (Nyquist–Shannon sampling theorem). So the high-frequency components of the (I guess white) noise are eliminated and so the noise-power gets lower. The sony-engineers decided to use that noise-drop to upgrade the light sensitivity by appling gain. So the ex1 has the same noise at all resolutions but different sensitivities.
Dominik Seibold is offline   Reply With Quote
Old November 30th, 2008, 11:23 PM   #17
Major Player

Join Date: Sep 2008
Location: Las Vegas, NV
Posts: 628
Quote:
Originally Posted by Dominik Seibold View Post
I compared 1080p with 6db (not 0db) to 720p with 0db, but anyway...

720p with x db gain compared to 1080p with x db gain is one stop brighter.
720p with x db gain compared to 1080p with x+6 db gain has (about) one stop less noise.
Why? Because 720p with x db is 1080p with x+6 db low-pass-filtered (=blurred).
From this it follows that if you blur 1080p with x db accordingly, you'll get 720p with x-6 db.
If x<6, then it's not possibly to get that 720p-result in the camera, but only in post with 1080p-footage.

One conclusion is:
If there's enough light to film with 1080p with <6db gain and you want the lowest noise possible (and you don't need a framerate higher than 30fps), use 1080p instead of 720p.
That's also true for 1080i, because it's also derived from 1080p with 6db extra-gain.
This actually reflects my first tests with the Ex3. I compared all the different recording formats in the same light and using all the different gains. After it was all said and done, the winner in my eyes was always 1080p. Some of the others were brighter but you don't want a bright image, what you really want is to see details in low light. I could see more in the available light at 1080p than I could with noisey 720p or 1080i for that matter.
Erik Phairas is offline   Reply With Quote
Old December 1st, 2008, 04:30 AM   #18
Inner Circle

Join Date: Dec 2005
Location: Bracknell, Berkshire, UK
Posts: 4,957
Quote:
Originally Posted by Dominik Seibold View Post
So the ex1 has the same noise at all resolutions but different sensitivities.
My point exactly. The camera is more sensitive for the same amount of noise by using 720P.
__________________
Alister Chapman, Film-Maker/Stormchaser http://www.xdcam-user.com/alisters-blog/ My XDCAM site and blog. http://www.hurricane-rig.com
Alister Chapman is offline   Reply With Quote
Old December 1st, 2008, 04:49 AM   #19
Major Player

Join Date: May 2008
Location: Nuremberg, Germany
Posts: 285
Quote:
Originally Posted by Alister Chapman View Post
The camera is more sensitive for the same amount of noise by using 720P.
Yes, but you're sacrificing resolution. I wouldn't recommend that.

Another example:
Imagine you have a noisy photo, and you want to print it. Would you really blur it before printing to reduce noise? Well, I wouldn't.
Dominik Seibold is offline   Reply With Quote
Old December 1st, 2008, 01:44 PM   #20
Inner Circle

Join Date: Dec 2005
Location: Bracknell, Berkshire, UK
Posts: 4,957
Depends on what you are doing. Excessive noise is a good way to get your programme to fail an HD broadcasters QA checks. Noise is the enemy of modern low bandwidth broadcasts.
__________________
Alister Chapman, Film-Maker/Stormchaser http://www.xdcam-user.com/alisters-blog/ My XDCAM site and blog. http://www.hurricane-rig.com
Alister Chapman is offline   Reply With Quote
Old December 1st, 2008, 05:42 PM   #21
Regular Crew

Join Date: Mar 2008
Location: Indian Rocks Beach, FL
Posts: 165
Erik I loved the video

I really enjoyed the Halloween video. Would you be so kind as to share the settings with me for that light? I will enter them into my EX1 profiles.

Phil
Phil Hanna is offline   Reply With Quote
Old December 1st, 2008, 10:36 PM   #22
Major Player

Join Date: Sep 2008
Location: Las Vegas, NV
Posts: 628
Quote:
Originally Posted by Phil Hanna View Post
I really enjoyed the Halloween video. Would you be so kind as to share the settings with me for that light? I will enter them into my EX1 profiles.

Phil
Oh it was very simple. picture profile STD4, I pushed the gamma all the way to +99, black is +1, and black gamma was +5. Plus I always use 1080p and try to keep the gain no higher than +9 for night shots because it keeps the noise in check. If I need more than +9 gain I like to use the 2 frame slow shutter instead. Although you really have to pan and tilt slowly for that..

I am still playing with the black gamma, and black level but you can see in the video they don't look too bad.

Also have some night video in this with the same settings.

Dumont Dunes Halloween on Vimeo

I'm going to try and push black gamma even higher next time I go out, and then return it to +5 to do a side by side, see which one I like best.
Erik Phairas is offline   Reply With Quote
Old December 2nd, 2008, 02:13 PM   #23
Major Player

Join Date: May 2008
Location: Nuremberg, Germany
Posts: 285
You forgot to mention your knee-settings.
Dominik Seibold is offline   Reply With Quote
Old December 2nd, 2008, 07:40 PM   #24
Major Player

Join Date: Sep 2008
Location: Las Vegas, NV
Posts: 628
Quote:
Originally Posted by Dominik Seibold View Post
You forgot to mention your knee-settings.
I am still learning all this stuff, I haven't touched that yet. :) I guess I will go play with it.
Erik Phairas is offline   Reply With Quote
Old December 2nd, 2008, 11:21 PM   #25
Major Player

Join Date: Sep 2008
Location: Las Vegas, NV
Posts: 628
just to put a finer point on it.. let's see one of the other cameras do this. :)

The Orion nebula. 16 frame slo shutter. A little post gain and offset adjustment. I'd love to try this with a lens that can do 50X or something. (open the photo and zoom in to see the nebula. Very hard to capture on video)
Attached Thumbnails
Low light setup on EX1 Help, please-orion.jpg

Last edited by Erik Phairas; December 3rd, 2008 at 06:29 PM.
Erik Phairas is offline   Reply
