Old April 23rd, 2010, 11:14 AM   #16
Major Player

Join Date: Jun 2006
Location: San Diego, CA
Posts: 203
Adding to what Serena said, detail setting will also change perceived depth of field.
As detail is increased, the softer focused portions of the image will be progressively sharpened, increasing the apparent depth of field.

This also makes it tough to find useful comparison shots without doing side-by-side camera tests. But the result of those identical shots would be, a little shallower for the EX, not a lot.
George Strother is offline   Reply With Quote
Old April 23rd, 2010, 11:48 AM   #17
Major Player

Join Date: Jul 2003
Location: Leeds, UK
Posts: 660
Images: 10
Some EX1 frame grabs

Here's some images for you.
Attached Thumbnails
Depth of field comparison EX1 and Z1. Please help!-eng_0097_01-dv.jpg   Depth of field comparison EX1 and Z1. Please help!-eng_0311_01-dv.jpg

Depth of field comparison EX1 and Z1. Please help!-eng_0140_01-dv.jpg   Depth of field comparison EX1 and Z1. Please help!-eng_0146_01-dv.jpg

Depth of field comparison EX1 and Z1. Please help!-eng_0216_01-dv.jpg   Depth of field comparison EX1 and Z1. Please help!-eng_0233_01-dv.jpg

Depth of field comparison EX1 and Z1. Please help!-eng_0252_01-dv.jpg   Depth of field comparison EX1 and Z1. Please help!-eng_0284_01-dv.jpg

__________________
FCPX/LS300/EX1/FS100/GoPro/Vinten/HotHead/Jib/Track/Dedos/Lightstorm/Coollights
Duncan Craig is offline   Reply With Quote
Old April 23rd, 2010, 05:10 PM   #18
Major Player

Join Date: Dec 2009
Location: Sacramento, California
Posts: 560
Great images - Exactly what I was looking for.....

Obviously the EX has a shallower depth of field and that is quite clear seeing these images below.
Silas Barker is offline   Reply With Quote
Old April 23rd, 2010, 06:12 PM   #19
Trustee

Join Date: Jun 2007
Location: Toronto
Posts: 1,414
hey Silas,
if DOF is so important to you, have you thought about DSLR option?
In the controllable light situation T2i and 70-200mm will be much cheaper, have better image and give you paper thin DOF
__________________
I love this place!
Buba Kastorski is offline   Reply With Quote
Old April 23rd, 2010, 06:39 PM   #20
Major Player

Join Date: Dec 2009
Location: Sacramento, California
Posts: 560
I did nt realize that that had shallower DOF, but I wanted something that records longer as well.

All the same, any sample images you can post on here?
Silas Barker is offline   Reply With Quote
Old April 23rd, 2010, 09:51 PM   #21
Major Player

Join Date: Jun 2006
Location: Studio Alnitak, Melbourne, Victoria, Australia
Posts: 640
Images: 3
Really? The sensor on a Canon 5D Mk II is 36 x 24 mm. Perhaps you're not familiar with calculating DoF? A good example of 5D images can be seen in: YouTube - Explosion- the Canon 5D MarkII
Serena Steuart is offline   Reply With Quote
Old April 23rd, 2010, 10:13 PM   #22
Major Player

Join Date: Dec 2009
Location: Sacramento, California
Posts: 560
I do not have u-tube access currently but my understanding was thet DOF is dependent upon sensor size and a iris thats open most of the way.... is that correct?
Silas Barker is offline   Reply With Quote
Old April 24th, 2010, 12:03 AM   #23
Major Player

Join Date: Jun 2006
Location: Studio Alnitak, Melbourne, Victoria, Australia
Posts: 640
Images: 3
I was interested that you found useful the images Duncan kindly posted. What did you learn from those that was specific to your question? That it is possible to render a background somewhat out of focus? DoF is one of those fundamentals of photography, so this should not be a matter for confusion. Perhaps such technical knowledge is thought arcane in these days of automatic cameras. The short answer to your question is to refer you to Wiki: Depth of field - Wikipedia, the free encyclopedia and you should take the time to understand the factors involved.

Strictly, an image formed by a lens is focused at only at a single subject distance from the lens, the image at all other distances being out of focus. However the amount of fuzziness increases with distance before and after the focus point, so the viewer will not observe fuzziness that is less than some threshold. The distance between those threshold points constitutes the DoF. Since it is the viewer who identifies where fuzziness begins, then DoF depends on viewing conditions, so the same image will appear to have much deeper DoF on an iPod than on a cinema screen.

Generally tables of DoF as a function of lens focal length and aperture vs subject distance are constructed for specific film/video formats for viewing in cinema conditions. Or (in stills) for viewing a specific sized print at a specific distance. Or, these days, on iPod, laptop, or TV, or cinema. So Tom Hardwick was correct "there are just too many variables" to provide the simplistic answer you seem to want. The figure I calculated for EX1/Z1 answers the question, but you have to understand what that means.
If you haven't access to YouTube, there is a better example of the 5D at
Serena Steuart is offline   Reply With Quote
Old April 24th, 2010, 12:14 AM   #24
Major Player

Join Date: Dec 2009
Location: Sacramento, California
Posts: 560
Thanks for all that, I know all about DOF.

The question I had was concerning how much shallower can you get with the EX then Z1.

I believe I will have the answer on Wednesday when it comes in the mail.

Thanks everyone.
Silas Barker is offline   Reply With Quote
Old April 24th, 2010, 12:33 AM   #25
Major Player

Join Date: Jun 2006
Location: Studio Alnitak, Melbourne, Victoria, Australia
Posts: 640
Images: 3
Excellent; glad that I was wrong in interpreting your response as ignorance. Then you understood that the answer, without waiting for the postman, is the DoF with the EX1 is 44% of that of the Z1. And that the Canon 5D has only 4% of the Z1 DoF.
Serena Steuart is offline   Reply With Quote
Old April 24th, 2010, 12:46 AM   #26
Major Player

Join Date: Dec 2009
Location: Sacramento, California
Posts: 560
Yes....however I did not realize anything about the 5D till a little late.

How does the image sensor compare on the 5D to the Ex in size?
Most specs showed the 5D in mm and the Ex in inches.

With the 5D is there a audio input and have you been able to compare the EX with the 5D?
Also I would need to shoot in multiple frame rates, and I am not sure if the 5D does or not.

Also.... how long can you record on a card with the 5D?

And is having one sensor look as good as far as colors and such? (good as Ex1r)
Silas Barker is offline   Reply With Quote
Old April 24th, 2010, 01:16 AM   #27
Major Player

Join Date: Jun 2006
Location: Studio Alnitak, Melbourne, Victoria, Australia
Posts: 640
Images: 3
OK, the 5D comparative figure is 1.7 inches vs the 0.5" for the EX1r. There is an audio input on the 5D, and I believe the audio capabilities have been enhanced in the latest firmware upgrade. I don't have a 5D Mk II (only the Mk I) so suggest you drop in on Canon EOS 5D Mk. II for HD Forum at DVinfo.net. I can tell you that several well experienced DOPs are using the 5DMkII (Victor Milt - the Delray Film Festival trailer- for one). You can read tests on DSLRs for video at: ProVideo Coalition.com: Picture Elements by Richard Harrington
Serena Steuart is offline   Reply With Quote
Old April 24th, 2010, 01:20 AM   #28
Major Player

Join Date: Dec 2009
Location: Sacramento, California
Posts: 560
Wow...1.7" - thats awesomeness!

I was reading on some other threads that the 5D really can not replace the Ex and also that its not so great handheld. But for certain uses I can see that this 5D camera would be very handy.

http://www.dvinfo.net/forum/sony-xdc...5d-better.html

I'll check out the info and thanks for sending it!

Who knows - I may end up sending my brand new EX1 back when it gets here and getting the 5D!
Although it would be really great to have at least 1 hour recording time so that its more useful to me for different purposes.
Silas Barker is offline   Reply With Quote
Old April 24th, 2010, 02:48 AM   #29
Major Player

Join Date: Jun 2006
Location: Studio Alnitak, Melbourne, Victoria, Australia
Posts: 640
Images: 3
Yes, the Canon 5D isn't a run-n-gun camera and anyway shallow DoF isn't something you want in that work. Really you need to set it up with zacuto rails with follow focus and matte-box and a separate recorder, so there are added costs. On the other hand, it can be used "as is". If what you want is precise control of DoF, superior low light performance and great images, then the 5D will give all that. As one DOP said of the problems of the 5D being a still camera first and a video camera second: "I NEVER said it was EASY! It's a pain in the butt, for sure. It's so like the old days with 35mm, critical focus, exact exposures, no auto-anything...but call me old fashioned (I guess you already have) - I love the control that this camera gives me. No way is it "run and gun" and NO WAY is it forgiving. And getting sound from the location to the finished video will give you nightmares - but it's my favourite camera (for now)."

Last edited by Serena Steuart; April 24th, 2010 at 03:19 AM.
