Marvel's Film Look PP and shutter speeds

I shot some video yesterday using Marvel's film look picture profile below. I like the look and I've used it several times. But one thing I noticed from yesterday's shoot is I got some funky looking 'strobing' effect from a simple pan of the camera. I shot it using a 1/60 shutter speed. I'm new to this camera and would appreciate some feedback on this. It seems to me that simple pans of people walking in normal speeds should not be problematic. It's not like I was shooting a basketball game or car racing! Did the shutter speed have anything to do with the PP settings or was it a function of the shutter speed setting. Please advise. Thanks.

Chuck

MARVELS FILM PICTURE PROFILE:

Matrix: On, High-Sat, Level 0, Phase -5, R-G 75, R-B 0, G-R -18, G-B -23, B-R -27, B-G 13. This gives a beautifully balanced color matrix.
White: on, Offset A +2, Offset B +2, Offset ATW +2. This will give you a beautiful warm picture, by elevating the reds a little bit
Detail: On, Level 0, Frequency +65, Crispening 0, Black limiter +75, White limiter +75. This gives a very nice definition without the artificial sharpening artifiacts. Ideal for DOF adapter shooting.
Gamma: Cine-1 for rich-contrast situations, Cine-3 for low-contrast situations. Make cine-1 your standard and avoid cine-4 (too noisy in the shadows). Use Joe’s Levels plugin for FCP to enhance contrast in post.
Black: -3 or -4 (use the Adobe OnLocation waveform monitor or another soft- or hardware level monitor, then cap the lens, set camera to Gain-0 and you’ll see that only -3 produces the correct black level – lower will crush the blacks. It’s better to control the blacklevel per-scene in post. -4 will give you zero pedestal; giving you a tiny bit more headroom. June 6 2009 update: i nowadays set black level to 0 (zero) and adjust the black level in post with FCP using Joe’s levels plugin. This further helps reducing noise in dark parts of the image!
Black gamma: -2. Will help to reduce noise in the blacks.
Charles Penn is offline   Reply With Quote
Old May 15th, 2010, 06:41 AM   #2
Regular Crew

Join Date: Dec 2009
Location: Ontario, Canada
Posts: 35
I've been using a slightly tweaked version of this PP for indoors and outdoors with good results. I haven't noticed any strobing but I haven't been doing a lot of pans lately.

This PP has become my default for in and out, when I just want to flip on the camera and go. Very flexible with a great natural look for outdoor.

So thanks for posting this PP, Charles.
Nathan Swinn is offline   Reply With Quote
Old May 15th, 2010, 08:28 AM   #3
Major Player

Join Date: Aug 2008
Location: Salida, Colorado
Posts: 555
Since Picture Profiles don't work cross model, is there any chance we can get you two to tell us what camera you're talking about? Thanks.
Charles Newcomb is offline   Reply With Quote
Old May 15th, 2010, 09:15 AM   #4
Trustee

Join Date: Jul 2007
Location: Novato, CA
Posts: 1,772
Charles,

I thought that the actual settings for the EX1 and EX3 were compatible. It is just that you cannot swap SUF files between the two cams. I've used the same settings from EX1's with my EX3 on multicam shoots and they matched fine.

Nathan,

What are your tweaks for indoor and outdoor?

Garrett
Garrett Low is offline   Reply With Quote
Old May 15th, 2010, 09:23 AM   #5
Regular Crew

Join Date: Dec 2009
Location: Ontario, Canada
Posts: 35
Certainly. EX1R here.

YouTube - CallanHDtest4.mov

Last edited by Nathan Swinn; May 15th, 2010 at 09:24 AM. Reason: bah
Nathan Swinn is offline   Reply With Quote
Old May 15th, 2010, 09:45 AM   #6
Major Player

Join Date: Aug 2008
Location: Salida, Colorado
Posts: 555
Okay, now I'm confused. Doug Jensen has repeatedly said EX1 and EX3 pictures profiles are different.
Charles Newcomb is offline   Reply With Quote
Old May 15th, 2010, 10:09 AM   #7
Regular Crew

Join Date: Dec 2009
Location: Ontario, Canada
Posts: 35
Garrett, cross posted with you.

I run the same profile, in and out. I'll dig out the settings and get them posted when I get the chance. In no way should my tweaking be considered scientific, haha. I somewhat randomly changed some of the Marvel settings.

That youtube vid is straight out of Avid, from early April, and was an early export test so it could probably look better.
Nathan Swinn is offline   Reply With Quote
Old May 16th, 2010, 07:00 AM   #8
Regular Crew

Join Date: Nov 2007
Location: Manhattan, Kansas
Posts: 123
I can't be sure what the OP meant by strobing, so I'm taking a shot in the dark here.

I don't use Detail On anymore because my EX1 had problems with the sharpening of fine detail popping in and out as the camera panned. This was especially bad when the scene included a lot of fine detail, such as bare tree branches.

My guess is that the onboard processing couldn't keep up. Even though the PP shows Detail set at 0, that still includes some sharpening. Others have posted here that you have to go to -20 or -30 to get no sharpening of detail.

Pete
Clark Peters is offline   Reply With Quote
Old May 16th, 2010, 08:45 AM   #9
Regular Crew

Join Date: Mar 2009
Location: Kibbutz Ein-Hashofet, Israel
Posts: 130
Marvel Film PP

Well, I shot an interview today, and decided to try this PP and see how it goes.
I think it looks decent, but there is room for improvement.
I used tungsten lights, and WB was set to 3200K.
Only the backlight was gelled with CTB.
I think the resulting image is still somewhat reddish.

I am attaching two frame grabs from the interview, and a 30 sec. clip.
Tell me what you think...

Thanks.
Attached Thumbnails
Marvel's Film Look PP and shutter speeds-interview01.jpg   Marvel's Film Look PP and shutter speeds-interview02.jpg

Attached Files
File Type: mov INTR000.mov (16.00 MB, 410 views)
Arbel Rom is offline   Reply With Quote
Old May 16th, 2010, 11:55 AM   #10
Inner Circle

Join Date: Dec 2005
Location: Bracknell, Berkshire, UK
Posts: 4,957
On any camera detail correction will drop off whenever the image moves or there is motion in the scene. This is because the detail circuits use contrast between adjacent pixels to determine where to apply detail. If the image is static then pixel to pixel contrast changes are easily determined, but if the image is moving you don't get the same difference between pixels and the detail enhancement level drops off as a result.
A camera with excessive detail correction or very high frequency correction will exhibit a noticeable softening of the image as a pan starts.

More advanced cameras such as the PMW-350 and PDW-700 have an additional sharpening circuit called "aperture correction" that works differently to detail and is not affected by motion in the same way.

With regard to the strobing, one thing to check is that you have "Flicker Reduce" in the camera menu set to "Off". It's known to cause issues when using the shutter. Also what are you monitoring with? Computer monitors are notorious for introducing artifacts that are not really there.
__________________
Alister Chapman, Film-Maker/Stormchaser http://www.xdcam-user.com/alisters-blog/ My XDCAM site and blog. http://www.hurricane-rig.com
