Old February 1st, 2008, 08:16 PM   #1
Major Player

Join Date: Jun 2007
Location: Rossland, British Columbia
Posts: 966
Raynox HDP 9000EX 1.8x tele lens

Hi all,
I posted a picture of me & my camera in another thread & there was a lot of interest in my lens & i was asked to post some pics. I am using it with a Canon XH A1 & am very happy so far with it's performance. Please note though, that i am pretty much a rank amature in the world of film making so my eye for what is good probably won't be up to most of the people here on the forum.

From top left is the helmet at a distance of 10 meters without the Raynox lens fitted & at full zoom.
Top right is also 10 meters with the Raynox lens. Also at full zoom.
Bottom left is the helmet at a distance of 6.5 meters without the Raynox lens fitted & at full zoom.
Bottom right is also 6.5 meters with the Raynox lens. Also at full zoom.
All photos were taken with the photo function to card, the first 3 on full Auto but manually focused. The bottom right picture i had to close the iris a bit to stop the picture blowing out.
Attached Thumbnails
Raynox HDP 9000EX 1.8x tele lens-canon-10m.jpg   Raynox HDP 9000EX 1.8x tele lens-raynox-10m.jpg

Raynox HDP 9000EX 1.8x tele lens-canon-6.5m.jpg   Raynox HDP 9000EX 1.8x tele lens-raynox-6.5m.jpg

__________________
There's never enough hours in the day!
Bryce Comer is offline   Reply With Quote
Old February 1st, 2008, 09:45 PM   #2
Inner Circle

Join Date: Jun 2005
Location: Saskatchewan
Posts: 3,004
Bryce,

thankyou for going to the trouble of making the comparisons!!

Are you knowledgeable enough to take stills out of your video footage for a similar comparison??

I am very impressed with the clearity of the 1.8x !!!

would love to try one on my gl2!!!
__________________
DATS ALL FOLKS
Dale W. Guthormsen
Dale Guthormsen is offline   Reply With Quote
Old February 1st, 2008, 09:59 PM   #3
Major Player

Join Date: Jun 2007
Location: Rossland, British Columbia
Posts: 966
Hi Dale,
I should be able to take some clips off some video if you like. What would you like to see?

Bryce
__________________
There's never enough hours in the day!
Bryce Comer is offline   Reply With Quote
Old February 1st, 2008, 10:47 PM   #4
Inner Circle

Join Date: Jun 2005
Location: Saskatchewan
Posts: 3,004
Bryce,

Actually the same test but from video captures would be awesome.
__________________
DATS ALL FOLKS
Dale W. Guthormsen
Dale Guthormsen is offline   Reply With Quote
Old February 1st, 2008, 11:02 PM   #5
Trustee

Join Date: Dec 2006
Location: Central Coast - NSW, Australia
Posts: 1,420
that's great - I'm really tempted. it will be really interesting to see some footage or stills taken from the same.
__________________
Cheers - Paul M.
www.relivetheday.com.au : www.perbenyik.com
Paul Mailath is offline   Reply With Quote
Old February 2nd, 2008, 03:49 AM   #6
Regular Crew

Join Date: Jan 2008
Location: Oslo, Norway
Posts: 175
This was really nice :)
I found some test video of the raynox lens on youtube as well. Just search Raynox 9000 or similar. Not the best video but it will give you an impression.

Still considering this lens myself, but have to save up some $ first.
Is there another lens that do even more closeups, that fits on the XH A1 (72mm) or is the raynox the best one?
Vegard Paulsen is offline   Reply With Quote
Old February 2nd, 2008, 05:00 AM   #7
Major Player

Join Date: Jun 2007
Location: Rossland, British Columbia
Posts: 966
Hi Vegard,
I believe that from a technical point of view, the Schnieder optics lens is even better. (Resolution wise that is) The Schnieder Optics lens is 1.6x i believe, but you might want to check that. Apart from these 2 i don't think there's much else around. Also, from what i've read, 1.6-1.8x is about as much as you would want to go. Can't tell you exactly why that is, but i do remember reading it somewhere. As i said in my first post, i'm no expert, so i can only really give you my opinion on what i see with using the Raynox & what i have researched about other lens' out there.

Bryce
__________________
There's never enough hours in the day!
Bryce Comer is offline   Reply With Quote
Old February 2nd, 2008, 05:19 AM   #8
Regular Crew

Join Date: Jan 2008
Location: Oslo, Norway
Posts: 175
tnx :)
youre probably right about that 1.8 is the most you can put on before other problems tend to come up.

I will check out the shneider optics as well.
I guess i just have to buy myself a bigger camera with changeable optics the next time. hehe.
Vegard Paulsen is offline   Reply With Quote
Old February 2nd, 2008, 01:02 PM   #9
Inner Circle

Join Date: Jun 2005
Location: Saskatchewan
Posts: 3,004
Good afternoon,

I have the scnieder optics 2x for my gl2. It is quality glass and as good as duplexes can get.

with a gl2 or A1 this is your only option.

You will always see softening at the far end of a duplex

I seldom use the full zoom capacity of the 2x for that reason.

I believe that is why they make 1.6 asnd 1.8 as that is the top end where you wont start seeing optic degradation. I would say I usually zoom to about 1.5 to 1.7.

I could post some comparisons on here if people wanted.
__________________
DATS ALL FOLKS
Dale W. Guthormsen
Dale Guthormsen is offline   Reply With Quote
Old February 12th, 2008, 07:30 AM   #10
Tourist

Join Date: Oct 2007
Location: Oulu Finland
Posts: 3
Well!

My Raynox arrived today from B&H (ordered Feb. 2nd, would have been here already on 7th but i was on a business trip)! I'm happy to say that in contrast to my earlier post, it came with the lens shade :). What a relief. Now, if it only wasn't so dark here after work. Maybe i'll have to wait until weekend for tests.

Edit (Sorry, removed the link to post as it didn't open in a new window)

Heimo

Last edited by Heimo Vepsa; February 12th, 2008 at 08:10 AM.
Heimo Vepsa is offline   Reply With Quote
Old March 2nd, 2008, 09:42 PM   #11
Trustee

Join Date: Dec 2006
Location: Central Coast - NSW, Australia
Posts: 1,420
Just wondering - does the Raynox allow the autofocus function or do you have to focus manually?
__________________
Cheers - Paul M.
www.relivetheday.com.au : www.perbenyik.com
Paul Mailath is offline   Reply With Quote
Old March 3rd, 2008, 07:24 PM   #12
Major Player

Join Date: Oct 2004
Location: Eugene, Oregon
Posts: 905
Autofocusing with Telextenders

For almost 4 years, I've been using my Raynox DCR-2020PRO, which is a 2.2X telextender, on all my camcorders and still cameras. I've found that the autofocus works just fine, in all cases. The Raynox 9000 is an even larger lens, but less powerful, so I'd expect that it wouldn't hamper autofocusing, either. The 2020PRO would probably be very adequate for use on larger HD camcorders, but its 62mm mounting-thread diameter will cause vignetting through most if not all the zoom range on the 72mm models. On my 58mm VX2100, it vignettes at any zoom point below about 90%, but is still very useful for long wildlife shots. The 2020PRO has a resolution rating of 260 lines-per-mm and causes no loss of detail on an 8-megapixel still camera. The Raynox 9000 has a 340 line-per-mm rating, so it would be more than sharp enough for any video imaging.
J. Stephen McDonald is offline   Reply With Quote
Old July 3rd, 2009, 03:27 AM   #13
New Boot

Join Date: Dec 2008
Location: Netherlands
Posts: 6
Hi guys,

I'm curious, did anyone make a test video with one of these teleconverters?
Rene de Haas is offline   Reply With Quote
Old July 3rd, 2009, 08:40 PM   #14
Trustee

Join Date: Dec 2006
Location: Central Coast - NSW, Australia
Posts: 1,420
What do you mean a 'test' video - do you want footage with and without the Raynox?

The pics in the 1st post give you a good idea of the difference
__________________
Cheers - Paul M.
www.relivetheday.com.au : www.perbenyik.com
Paul Mailath is offline   Reply With Quote
Old July 7th, 2009, 04:13 AM   #15
New Boot

Join Date: Dec 2008
Location: Netherlands
Posts: 6
Hi Paul,

I ment video's shot with teleconverters. I read about Ranynox, Canon, Schnieder. I would like to compare these.
Rene de Haas is offline   Reply
