Vimeo upload, source is 720 x 480, 29.970i

The only template that is 720 x 480 is Main Concept MPEG-2, DVD Architect NTSC Video Stream, but the resulting file is VIDEO_TS, with a bunch of VOB files inside. I couldn't upload those files to Vimeo. What am I doing wrong?
Thanks,
Norris Combs is offline   Reply With Quote
Old May 22nd, 2013, 05:01 AM   #2
Major Player

Join Date: Oct 2012
Location: Riga, Latvija, EU
Posts: 280
Re: Vimeo upload, source is 720 x 480, 29.970i

Compression Guidelines on Vimeo
You can create custom template for vimeo.
Juris Lielpeteris is offline   Reply With Quote
Old May 22nd, 2013, 12:54 PM   #3
Major Player

Join Date: Apr 2008
Location: OC, CA
Posts: 340
Re: Vimeo upload, source is 720 x 480, 29.970i

Thanks Juris, I did read through that. But, the chart doesn't show any 720 x 480. Does that mean I'll need to downgrade my 720 x 480 video to 640 x 480?
Norris Combs is offline   Reply With Quote
Old May 22nd, 2013, 01:41 PM   #4
Major Player

Join Date: Oct 2012
Location: Riga, Latvija, EU
Posts: 280
Re: Vimeo upload, source is 720 x 480, 29.970i

Yes, because internet video always use square pixels, vimeo otherwise can incorrectly set aspect ratio.
Juris Lielpeteris is offline   Reply With Quote
Old May 22nd, 2013, 11:29 PM   #5
Trustee

Join Date: Oct 2009
Location: Central Coast Australia
Posts: 1,008
Re: Vimeo upload, source is 720 x 480, 29.970i

Another way,
If you convert your video to square pixels you end up with approx 872x 480, depending on the quality of your footage you may be better off to drop it into a 1280x 720 project (upscaling it).
This will at least give you a HD version when you upload it.
I do this all the time with PAL footage, 720x576 into square pixels = 1050x576, then to 1280x720. Not that much of a stretch.
You can clean and sharpen it a bit and results are pretty good. see pic.
Attached Thumbnails
Vimeo upload, source is 720 x 480, 29.970i-pal-720p.jpg
__________________
http://vimeo.com/livewebvideo
Gerald Webb is offline   Reply With Quote
Old May 22nd, 2013, 11:51 PM   #6
Inner Circle

Join Date: Sep 2003
Location: Portland, Oregon
Posts: 3,259
Re: Vimeo upload, source is 720 x 480, 29.970i

Quote:
Originally Posted by Gerald Webb View Post
Another way,
If you convert your video to square pixels you end up with approx 872x 480, depending on the quality of your footage you may be better off to drop it into a 1280x 720 project (upscaling it).
This will at least give you a HD version when you upload it.
I do this all the time with PAL footage, 720x576 into square pixels = 1050x576, then to 1280x720. Not that much of a stretch.
You can clean and sharpen it a bit and results are pretty good. see pic.
Though Gerald's advice is solid, the details need a little modification for NTSC, especially if you've not worked through this math before.

If your standard def is wide-screen 16:9, then 854x480 is an excellent square-pixel format that slightly scales up the horizontal resolution so as to preserve the full vertical resolution.

If your standard def is full-screen 4:3, 640x480 square pixels preserves full vertical resolution at a slight reduction in horizontal resolution. Or, to scale up the vertical and preserve existing horizontal rez, 720x540 square pixels.

As mentioned earlier in this thread, square pixels, aka. PAR=1.0, is always a good idea for online distribution. It's become a best practice because although the widescreen or anamorphic flag is recognized by some encoders for some codecs some of the time, square pixels are recognized by all encoders and players for all codecs all of the time.

Vimeo's SD/HD switch works with standard HD video resolutions, 1280x720 works... but e.g. 854x480 will transcode at Vimeo to 854x480 only. If you up-scale the same clip to 1280x720 and upload, you'll end up with good-looking HD as well as available SD, after Vimeo's transcoding.
__________________
30 years of pro media production. Vegas user since 1.0. Webcaster since 1997. Freelancer since 2000. College instructor since 2001.
Seth Bloombaum is offline   Reply With Quote
Old May 23rd, 2013, 12:18 AM   #7
Trustee

Join Date: Oct 2009
Location: Central Coast Australia
Posts: 1,008
Re: Vimeo upload, source is 720 x 480, 29.970i

Thanks Seth,
Im just a PAL man, lol.
Principle is good though, Widescreen SD to 720p is achievable.
__________________
http://vimeo.com/livewebvideo
Gerald Webb is offline   Reply With Quote
Old May 23rd, 2013, 11:26 PM   #8
Major Player

Join Date: Apr 2008
Location: OC, CA
Posts: 340
Re: Vimeo upload, source is 720 x 480, 29.970i

Quote:
Originally Posted by Seth Bloombaum View Post

If your standard def is full-screen 4:3, 640x480 square pixels preserves full vertical resolution at a slight reduction in horizontal resolution. Or, to scale up the vertical and preserve existing horizontal rez, 720x540 square pixels.

Please help a noob here.
Yes, my footage is full screen (4:3) 720 x 480. So do I want to render it to 640 x 480 (preserving vertical resolution), or do I want 720 x 540 (preserving horizontal resolution)?
Thanks,
Norris Combs is offline   Reply With Quote
Old May 24th, 2013, 12:55 AM   #9
Major Player

Join Date: Oct 2012
Location: Riga, Latvija, EU
Posts: 280
Re: Vimeo upload, source is 720 x 480, 29.970i

Vimeo recomends
Quote:
4:3 aspect ratio 640 x 480 px
Size of real online 4:3 clips is also 640 x 480 px

Last edited by Juris Lielpeteris; May 24th, 2013 at 01:35 AM.
Juris Lielpeteris is offline   Reply With Quote
Old May 24th, 2013, 01:16 AM   #10
Inner Circle

Join Date: Sep 2003
Location: Portland, Oregon
Posts: 3,259
Re: Vimeo upload, source is 720 x 480, 29.970i

Quote:
Originally Posted by Norris Combs View Post
...So do I want to render it to 640 x 480 (preserving vertical resolution), or do I want 720 x 540 (preserving horizontal resolution)?
Either.

Sorry there isn't a clear answer on this; now we're getting to the point of very small differences. There's certainly nothing wrong with 640x480, though on paper 720x540 is better. Whether it will look appreciably better depends on the footage.

In my experience Vimeo will take all sorts of oddball sizes, but only 1280x720 and 1920x1080 get transcoded to multiple sizes for playback. I've wondered about pillarboxing 4:3 material to 16:9 for Vimeo to take advantage of that, but never got around to trying it.

Do remember to select "best" in the custom settings for Vegas rendering when changing resolutions.

OTOH, when working in 16:9 SD, 854x480 is *much* better than 640x360 when converting to square pixels.
__________________
30 years of pro media production. Vegas user since 1.0. Webcaster since 1997. Freelancer since 2000. College instructor since 2001.
Seth Bloombaum is offline   Reply
