What is wrong looks like 3D whitout 3D glasses?

Hi
My name is Finn and this is my first post ever here in this forum. Today I recieved my Canon XL H1, and it just looks great. But when I turne it on and looks through the WF it all looks totally wrong. It actually looks like watching a 3D movie without 3D glasses.
What is wrong and what can I do?
If anybody can help me I will be very, very happy.
I'm a totally novice on this camera.
Best regards from Finn
Finn Noer is offline   Reply With Quote
Old April 13th, 2007, 11:22 PM   #2
Trustee

Join Date: Mar 2006
Location: Vancouver Island, Canada
Posts: 1,200
Finn,

Did you try rotating the sliding diopter adjustment on top (and bottom) of the rubber eyecup?
__________________
C100, 5DMk2, FCPX
Ken Diewert is offline   Reply With Quote
Old April 13th, 2007, 11:31 PM   #3
Obstreperous Rex

Join Date: Jan 2001
Location: San Marcos, TX
Posts: 26,900
Images: 513
After focusing the diopter per Ken's suggestion above, if it still doesn't look right, flip the diopter up so that you're looking directly at the LCD panel. If the problem is still there, then you need to return the camera for service.
__________________
CH

Search DV Info Net | DV Info Net Sponsors | A Decade (+5) of DVi | ...Tuesday is Soylent Green Day!
Chris Hurd is offline   Reply With Quote
Old April 14th, 2007, 04:54 AM   #4
Major Player

Join Date: Nov 2005
Location: Vittsjö, SKÅNE, SWEDEN
Posts: 266
Exposure way to hot perhaps?

Hello Finn,
Nice to meet a neighbour here!
Have you turned on an appropriate ND filter on the lens for the light situation? If the light is much stronger than the exposure selected you may see strange pictures in the VF. Put it on manual M and observe the exposure meter to be sure you are about in middle and not at the extremes ends.
Good luck! /Johan
Johan Forssblad is offline   Reply With Quote
Old April 14th, 2007, 06:27 AM   #5
New Boot

Join Date: Feb 2007
Location: Denmark
Posts: 9
Quote:
Originally Posted by Chris Hurd View Post
After focusing the diopter per Ken's suggestion above, if it still doesn't look right, flip the diopter up so that you're looking directly at the LCD panel. If the problem is still there, then you need to return the camera for service.
<Thanks for helping, but the problem is still there;-(
Finn Noer is offline   Reply With Quote
Old April 14th, 2007, 06:35 AM   #6
New Boot

Join Date: Feb 2007
Location: Denmark
Posts: 9
Quote:
Originally Posted by Johan Forssblad View Post
Hello Finn,
Nice to meet a neighbour here!
Have you turned on an appropriate ND filter on the lens for the light situation? If the light is much stronger than the exposure selected you may see strange pictures in the VF. Put it on manual M and observe the exposure meter to be sure you are about in middle and not at the extremes ends.
Good luck! /Johan
Hi Johan
Thanks for welcoming me this way;-)
The ND filter doesn't seem to have any influence on the way the gren red and blue colours behave. The colours looks like they allmost are totally seperated.
If possible I would like to get further assistance.
Do you have any other ideas?
HAve a nice weekend.

Best regards from Finn
Finn Noer is offline   Reply With Quote
Old April 14th, 2007, 06:37 AM   #7
New Boot

Join Date: Feb 2007
Location: Denmark
Posts: 9
Quote:
Originally Posted by Ken Diewert View Post
Finn,

Did you try rotating the sliding diopter adjustment on top (and bottom) of the rubber eyecup?
Hi Ken
I tried to do what you suggested, but id did not help.
Thank you for trying to help me.
Best regards from Finn

P.S. You are welcome to com with other suggestions;-)
Finn Noer is offline   Reply With Quote
Old April 14th, 2007, 07:09 AM   #8
New Boot

Join Date: Feb 2007
Location: Denmark
Posts: 9
Quote:
Originally Posted by Johan Forssblad View Post
Hello Finn,
Nice to meet a neighbour here!
Have you turned on an appropriate ND filter on the lens for the light situation? If the light is much stronger than the exposure selected you may see strange pictures in the VF. Put it on manual M and observe the exposure meter to be sure you are about in middle and not at the extremes ends.
Good luck! /Johan
Hi again
If anybody is interested, I can mail some pictures made by the camera. They look excatly the same as a video sekvens, and that is not good;-)
Best regards from

Finn
Finn Noer is offline   Reply With Quote
Old April 14th, 2007, 07:16 AM   #9
Inner Circle

Join Date: Oct 2004
Location: Port St. Lucie, Florida
Posts: 2,614
Finn,

Save yourself some time, and just get it packed up for return/repair. Sounds like something is out of alignment in the CCD area.

Return it or send it off for repair.

Mike
__________________
Chapter one, line one. The BH.
Mike Teutsch is offline   Reply With Quote
Old April 14th, 2007, 10:36 AM   #10
Major Player

Join Date: Nov 2005
Location: Vittsjö, SKÅNE, SWEDEN
Posts: 266
I'm sorry for you Finn. Terrible when you get a new toy to play with.
Perhaps the camera has got excessive G-forces in the shipping.
A friend who is professional videographer working with the big Sony machines tells me he usually takes a one chip camera if he is on vacation and puts the camera in checked luggage. He says a 3 CCD camera is very sensitive for the alignment of the CCDs relative each other and he has got three CCDs cameras out of alignment by dropping them.

Think it should be easy to check for this if you make a shot of a pair of white cross on a black background and make shure you have them in focus.

Good luck! /Johan
Johan Forssblad is offline   Reply With Quote
Old April 14th, 2007, 02:45 PM   #11
New Boot

Join Date: Feb 2007
Location: Denmark
Posts: 9
Hi Johan
If you are interested I can mail you the still picture-shots I made on a black and white sofa, looks interesting;-)
Have a nice weekend
Best regards from
Finn
Finn Noer is offline   Reply With Quote
Old April 14th, 2007, 02:52 PM   #12
New Boot

Join Date: Feb 2007
Location: Denmark
Posts: 9
Hi Johan
If this is the case (wrong CCD alignment), do you or your friend know if it is expensive to have fixed?
I bought the camera via Ebay 1 week ago, and the seller is allready informed about the problem, and he is of-course willing to take it back, but honestly I would prefer to have it fixed and just let him pay the bill.
Best regards from Finn
Finn Noer is offline   Reply With Quote
Old April 17th, 2007, 03:24 AM   #13
Major Player

Join Date: Nov 2005
Location: Vittsjö, SKÅNE, SWEDEN
Posts: 266
Hej Finn,
I think you have to ask a Canon service center to get a price indication for this. My friend dropped Sony cameras. If you like you could try to mail an example photo to me through this site. It could be interesting to view. However, I don't want to screw your camcorder; One pixel width out of alignment is less than 1/100 mm to correct so it is really a precision job to adjust it. /Johan
Johan Forssblad is offline   Reply With Quote
Old April 21st, 2007, 06:40 PM   #14
New Boot

Join Date: Feb 2007
Location: Denmark
Posts: 9
Photos from "damaged" Canon XL H1

Quote:
Originally Posted by Johan Forssblad View Post
Hej Finn,
I think you have to ask a Canon service center to get a price indication for this. My friend dropped Sony cameras. If you like you could try to mail an example photo to me through this site. It could be interesting to view. However, I don't want to screw your camcorder; One pixel width out of alignment is less than 1/100 mm to correct so it is really a precision job to adjust it. /Johan
Hi Johan
Here is the photos.
The sofa you can see is totally black and white "normaly"
Regards from
Finn
Attached Thumbnails
What is wrong looks like 3D whitout 3D glasses?-img_0159.jpg   What is wrong looks like 3D whitout 3D glasses?-img_0157.jpg

What is wrong looks like 3D whitout 3D glasses?-img_0158.jpg
Finn Noer is offline   Reply With Quote
Old April 22nd, 2007, 03:19 PM   #15
Major Player

Join Date: Nov 2005
Location: Vittsjö, SKÅNE, SWEDEN
Posts: 266
Hej Finn,
The links worked fine. Nice test photo sofa you have! Looks to me your red sensor is shifted a lot horisontally compared to the green and blue. Have you asked Canon in Denmark? I'm sorry you got this bad experience. Good luck /Johan
