Old April 24th, 2008, 06:22 AM   #1
Major Player

Join Date: Dec 2006
Location: Berlin and Geneva
Posts: 258
Short Film With Greenkey Scenes: 4:2:2

I'm shooting a short film in about 6 weeks' time in the Geneva area.
This is a project I'm shooting with freinds over a 4-day period, just for fun but totally professional cast, crew and equipment. No direct sound, ADR.
Using my Gy-HD251 with mini-35 400 and Zeiss HS lenses.
We'll record most scenes to the DR-HD100 in QT or m2t mode and camtape backup.
We have two greenkey scenes to be shot in a high-end studio near Geneva. (both take place in the building of some Global Population Formatting Bureau)

I figure it might make sense to shoot the greenkey scenes (ca. 5 min. in all) in 4:2:2 (10 bit ?) in order to facilitate the effects work to be done later on.

What's your opinion ? Anyone tried this out ? Using what hardware at the recording end ??

Thanks !

Attachments: STORYBOARD scenes 1 and 11
Attached Thumbnails
Short Film With Greenkey Scenes: 4:2:2-lo_scene_1_1.jpg   Short Film With Greenkey Scenes: 4:2:2-lo_scene_1_2.jpg

Short Film With Greenkey Scenes: 4:2:2-lo_scene_1_3.jpg   Short Film With Greenkey Scenes: 4:2:2-lo_scene_11_1.jpg

Claude Mangold is offline   Reply With Quote
Old April 24th, 2008, 10:43 AM   #2
Inner Circle

Join Date: Jan 2006
Posts: 2,290
nice storyboard

I think you need a fast raid and some sort of capture board.

btw people pull nice keys in 4.2.0 mode. Much better than dv.
Brian Luce is offline   Reply With Quote
Old April 24th, 2008, 02:44 PM   #3
Trustee

Join Date: Apr 2005
Location: Santa Cruz, CA
Posts: 1,116
IN terms of color information to pull the key 4:2:2 gives you just a marginal advantage compared to 4:2:0. You can pull perfectly good keys in 4:2:0 provided that the GS is lit correctly and evenly and the usual precautions are taken when shooting for chroma key. Where you will see an improvement is in the definition of edges like in the shoulder areas of the actors. There the higher color sampling will give you less "stair-stepping" than 4:2:0.
__________________
Paolo http://www.paolociccone.com
Demo Reel
Paolo Ciccone is offline   Reply With Quote
Old April 24th, 2008, 11:40 PM   #4
Major Player

Join Date: Dec 2006
Location: Berlin and Geneva
Posts: 258
Thanks Brian, Thanks Paolo,

Would the the small gain in edge definition be worth it in case it's transferred to film later on ?

But at this point it's just a project among pals, so the additional cost of that option and the local availability of the hardware would be decisive.

Is state of the art still a Mac with a Blackmagic card and a raid 0 ? fiber link also ? how much disk space if I have a shooting ratio of 6 i.e. 30 min. of takes ?
Claude Mangold is offline   Reply With Quote
Old April 25th, 2008, 01:52 AM   #5
Inner Circle

Join Date: Jan 2006
Posts: 2,290
Quote:
Originally Posted by Claude Mangold View Post
Thanks Brian, Thanks Paolo,

Would the the small gain in edge definition be worth it in case it's transferred to film later on ?

But at this point it's just a project among pals, so the additional cost of that option and the local availability of the hardware would be decisive.

Is state of the art still a Mac with a Blackmagic card and a raid 0 ? fiber link also ? how much disk space if I have a shooting ratio of 6 i.e. 30 min. of takes ?
There hasn't been many people shooting that way, with the raid and component capture. It's very cumbersome being tethered like that. I haven't even heard about many people using the jackpack on the HD250. The image to tape is really good.
Brian Luce is offline   Reply With Quote
Old April 25th, 2008, 11:32 AM   #6
Major Player

Join Date: Apr 2006
Location: Pacific NW
Posts: 431
I captured some HD100 component output from a blue screen live into our editing system with audio and there was a darn ground loop in the video signal, so it was useless. Thankfully it was only a test to see if it could be done.

I just did a greenscreen shoot in a cyclorama for a music video last week, recorded to HDV tape from the HD100.

The keying worked really well.
I edited the whole thing in final cut as HDV then exported it 10-bit uncompressed into after effects and used keylight. Then exported
that as 10-bit and put it back into the edit.

the whole thing turned out really good.
Mark Silva is offline   Reply With Quote
Old April 25th, 2008, 11:41 AM   #7
Trustee

Join Date: Apr 2005
Location: Santa Cruz, CA
Posts: 1,116
Quote:
Originally Posted by Claude Mangold View Post
Would the the small gain in edge definition be worth it in case it's transferred to film later on ?
To me it wouldn't be. I can pull a perfectly good key using Keylight in AE plus cleaning up the matte with KeyCorrect Pro which has excellent plugins to blur and/or feather the edges of the matte. A little bit of blurring both makes the subject merge better with the composited BG and takes care of the stairstepping.
__________________
Paolo http://www.paolociccone.com
Demo Reel
Paolo Ciccone is offline   Reply With Quote
Old April 28th, 2008, 08:49 AM   #8
Major Player

Join Date: Dec 2006
Location: Berlin and Geneva
Posts: 258
Thanks a lot, guys. We'll stick to HDV and try the 10-bit route via FCP and AE, especially since the strange atmosphere or the film suggest a kind of milky softness so a little edge blurring will blend in well.
Claude Mangold is offline   Reply
