HVL-LBP lamp, and batteries - Page 2 at DVinfo.net

Go Back   DV Info Net > Sony XAVC / XDCAM / NXCAM / AVCHD / HDV / DV Camera Systems > Sony HDV and DV Camera Systems > Sony HVR-V1 / HDR-FX7

Sony HVR-V1 / HDR-FX7
Pro and consumer versions of this Sony 3-CMOS HDV camcorder.


Reply

Thread Tools Search this Thread
Old August 4th, 2007, 11:49 AM   #16
Inner Circle

Join Date: Aug 2006
Location: Poland
Posts: 4,086
Ron,

The lamp is solid built, elegant and - using the same batteries as the V1 - convenient. However, it's also quite heavy; also you cannot count on the distance effectively lit to be longer that some 5-8 meters. Anything within this distance is very nicely brightened; you have a choice of a diffuser or concentrator flaps, and a dimmer control.

As a sample, here's a grab from a clip shot with the lamp in otherwise completely dark room - the distance was some 3-4 meters:
Attached Thumbnails
HVL-LBP lamp, and batteries-pot.jpg
__________________
Sony PXW-FS7 | DaVinci Resolve Studio; Magix Vegas Pro; i7-5960X CPU; 64 GB RAM; 2x GTX 1080 8GB GPU; Decklink 4K Extreme 12G; 4x 3TB WD Black in RAID 0; 1TB M.2 NVMe cache drive

Last edited by Piotr Wozniacki; August 5th, 2007 at 03:01 AM.
Piotr Wozniacki is offline   Reply With Quote
Old August 4th, 2007, 03:45 PM   #17
Major Player

Join Date: May 2005
Location: Europe
Posts: 844
One thing Piotr

The HVL-LBP is renowned to be somewhat cool on the color temperature. i.e. has a tendency to be a little bit blue'ish. It is, after all, daylight balanced and therefore under MIXED lighting (tungsten and the LBP itself) you would expect that people's faces, for examples, end up being slightly cool looking. If the LBP is ONLY source, then the cam's white-balance could more or less fix it, but under mixed indoor lighting, i am wondering if you find it's coolness (5600K balanced) a problem? If I got that light, i would think an amber filter would be needed to warm things up a little, but I have read some conflicting reports on whether thats necessary or not.

I would appreciate any feedback you could give on the LBP with reference to shooting people pics, especially indoors with other (warmer..) light sources in the room.

thanks in advance
Stu Holmes is offline   Reply With Quote
Old August 4th, 2007, 03:55 PM   #18
Inner Circle

Join Date: Aug 2006
Location: Poland
Posts: 4,086
Stu, I personally don't find it to pose any serious problems. I have found this clip as the first one handy, so apologies for the quality - but as you can see, my doughter's skin looks quite natural under the mixed light from a regular (weak) bulb and the LBP LED light... The camera was on AWB, and the lamp's diffuser flap on, if I remember correctly! Please comment - perhaps some flaws are there, and it's just me who cannot see them?

EDIT
I took another look at my own grab, and I can see the effect you're mentioning Stu. Not so much on the skin, but on the wall to the right: the closer to the lamp, the more bluish it is (or due to AWB, it's actually white); further away where the proportion of the yellow light from the bulb above to the LED light from the camera changes in favour of the bulb light - the wall turns a bit reddish...

EDIT 2
Inspired by the above 'discovery', I searched for other shootings with the HVL-LBP lamp. I'm posting a grab from the church where I shot a musical performance a while ago; this is the audience sitting in the first raw, within 1-3 meters from the camera, filmet at the moment I turned the camera on the tripod after the musicians finished, to catch the ovation. The WB I had set manually to objects at a much longer distance, seems completely wrong here - the faces are a bit bluish, indeed (especially when one compares the grab to the right with one of my other church grabs here:

http://www.dvinfo.net/conf/showpost....31&postcount=1)

Also, the grab looks ugly because the lamp's concentrator was on (rigth for the longer disctances, completely wrong here), and the beam was directed too high (also because it was set for the longer distance). These are not real faults, of course - it's just that there's no single setting of the lamp which is always right...
Attached Thumbnails
HVL-LBP lamp, and batteries-image17.jpg   HVL-LBP lamp, and batteries-image18.jpg

__________________
Sony PXW-FS7 | DaVinci Resolve Studio; Magix Vegas Pro; i7-5960X CPU; 64 GB RAM; 2x GTX 1080 8GB GPU; Decklink 4K Extreme 12G; 4x 3TB WD Black in RAID 0; 1TB M.2 NVMe cache drive

Last edited by Piotr Wozniacki; August 5th, 2007 at 04:57 AM.
Piotr Wozniacki is offline   Reply With Quote
Old August 5th, 2007, 06:35 AM   #19
Regular Crew

Join Date: Jul 2007
Location: Singapore
Posts: 173
Soon Im getting the SONY LED light and need sometime to adjust when is when to used :)
K.C. Luke is offline   Reply With Quote
Old August 5th, 2007, 08:47 AM   #20
Major Player

Join Date: Feb 2003
Location: Pensacola Fl.
Posts: 627
So, what is the answer should we have an amber filter?

How much would that hurt the lights performance?

Should I look to a more traditional light like the Varalux?

What if you took a Sony HVL-20DW2 20-watt Video Light and mounted it sideways for a more wide-screen profile?
Ron Little is offline   Reply With Quote
Old August 5th, 2007, 09:08 AM   #21
Inner Circle

Join Date: Aug 2006
Location: Poland
Posts: 4,086
Ron,
I've tried to answer you original question as exhaustively as I only could; now the decisions are yours;)

I can only add that my previous conventional tungsten lamp wasn't better in any aspect, and I had to carry a heavy bettery around which only lasted for 1/2 hour with a 100W bulb, or some 2 hours with a 35W one. The HVL-BP brightness is more comparable to the 100W tungsten version, and yet - with the 970 battery - it lasts for 3 hours between charges.
__________________
Sony PXW-FS7 | DaVinci Resolve Studio; Magix Vegas Pro; i7-5960X CPU; 64 GB RAM; 2x GTX 1080 8GB GPU; Decklink 4K Extreme 12G; 4x 3TB WD Black in RAID 0; 1TB M.2 NVMe cache drive
Piotr Wozniacki is offline   Reply With Quote
Old August 5th, 2007, 09:26 AM   #22
Major Player

Join Date: Feb 2003
Location: Pensacola Fl.
Posts: 627
Thank you Piotr. That was the information I was looking for. Your comparison to a 100w tungsten light puts it in terms I can understand. With the 970 you are getting three hours of burn. Is that continues?
Ron Little is offline   Reply With Quote
Old August 5th, 2007, 09:34 AM   #23
Inner Circle

Join Date: Aug 2006
Location: Poland
Posts: 4,086
Quote:
Originally Posted by Ron Little View Post
Thank you Piotr. That was the information I was looking for. Your comparison to a 100w tungsten light puts it in terms I can understand. With the 970 you are getting three hours of burn. Is that continues?
Frankly, I never actually tried to have it burning continuously for that long, this is what the specs are saying. However, after around 1 h of continuous work, I still saw 3 out of the 4 green diodes...
__________________
Sony PXW-FS7 | DaVinci Resolve Studio; Magix Vegas Pro; i7-5960X CPU; 64 GB RAM; 2x GTX 1080 8GB GPU; Decklink 4K Extreme 12G; 4x 3TB WD Black in RAID 0; 1TB M.2 NVMe cache drive
Piotr Wozniacki is offline   Reply With Quote
Old August 5th, 2007, 12:41 PM   #24
Major Player

Join Date: May 2005
Location: Europe
Posts: 844
Yes i think the ability of the light to run about 3 hours is great.

The problem with tungsten lights is that use much more power (LBP is only 16watts consumption) and tungsten lights need a pretty hefty powerpack which may only last 30-40minutes. And if the event you're shooting lasts longer than that what are you going to do?? Have ANOTHER hefty battery pack ? all a bit of a pain.

I think the LBP is fine, and, maybe, as long as you don't mind a small output loss, an amber gel filter may warm things up a little in certain circumstances.
Stu Holmes is offline   Reply With Quote
Old August 5th, 2007, 01:08 PM   #25
Major Player

Join Date: Feb 2003
Location: Pensacola Fl.
Posts: 627
Well, I am really starting to lean toward this light. I will probably buy one next month we have budget for one now and if all is well then the other one the next month. I love having two V1s but buying accessaries are double also. Thanks again for your help.
Ron Little is offline   Reply With Quote
Old August 6th, 2007, 03:33 AM   #26
Inner Circle

Join Date: Aug 2006
Location: Poland
Posts: 4,086
Quote:
Originally Posted by Ron Little View Post
What if you took a Sony HVL-20DW2 20-watt Video Light and mounted it sideways for a more wide-screen profile?
One more word on the ugly spot of light on the right one of the grabs above: it's perfectly possible to cover the whole area with even light, provided your subject is within the lamp's effective distance. To achieve that, it's enough to carefully position the light beam (some degrees downward), and engage diffusor rather than concentrator. Also, the LEDs are placed in a pattern that is well suited to the 16:9 aspect ratio; in fact, even with the Sony 0.8x wa adapter, it's possible to evenly brighten for instance a group of people from some 3-4 meters away.

So, don't misjudge the lamp's capabilities basing on that particular grab - I posted it in order to show possible problems and flaws, resulting from misconfiguration!
__________________
Sony PXW-FS7 | DaVinci Resolve Studio; Magix Vegas Pro; i7-5960X CPU; 64 GB RAM; 2x GTX 1080 8GB GPU; Decklink 4K Extreme 12G; 4x 3TB WD Black in RAID 0; 1TB M.2 NVMe cache drive

Last edited by Piotr Wozniacki; August 6th, 2007 at 05:41 AM.
Piotr Wozniacki is offline   Reply With Quote
Old August 6th, 2007, 05:24 PM   #27
Major Player

Join Date: Nov 2003
Location: WestChazy, NY
Posts: 291
I have this light and cut a small piece of CTO gel to fit against the glass for use indoors. It works like a charm and I just tape it to the glass, the lamp stays cool so it doesn't melt. If I need to use it outside, I just peel it off. I keep it in a small toilet paper roll when not in use!

I found it too blue indoors mixed with just incandescent lights, in a mixed light situation it works well with or without the gel.

I'm using it more and more and really like this light. FWIW! It works well on an overcast day to add that glint in a subjects eyes.

Last edited by Paul Frederick; August 6th, 2007 at 07:13 PM.
Paul Frederick is offline   Reply With Quote
Old August 6th, 2007, 06:09 PM   #28
Major Player

Join Date: Nov 2004
Location: Dallas
Posts: 747
Quote:
Originally Posted by Piotr Wozniacki View Post
Zsolt,

The question isn't silly at all, simply there are good lamps and... well, not so good ones. Regarding the light volume, the HVL-LBP is a LED lamp, rated 600 lux; it's also very efficient (3 hours with the 970 battery). Also, its shape is rectangular and corresponds well with the 16:9 scene proportions.

Of course, on-cam lamps are seldom strong enough to lit big areas and at a long distance. However, this one is OK for indoor shootings; for instance at a party in a dim room it's great to brighten people's faces (it has a dimmer, so is not very obtrusive).

Actually this is very misleading, they advertized the light at 600 lux, but forgot to mention like in the manual that it is 600 lux only will the intensifier, and when you use the intensifier it is very narrow beam and not spread out at all, but I still like it, it sure beat wearing a 17lbs battery pack for my old light.
BTW this light is 5600K so if you are using indoor, you should put a CTO filters on it, loose another 1/2 stop with the filter, as for using this with the V1, it will only be good less than 5 feet from your subject, V1 is not sensitive at all unnder low light.
__________________
Khoi Pham
www.proeditproductions.com
Khoi Pham is offline   Reply With Quote
Old August 7th, 2007, 04:23 AM   #29
Inner Circle

Join Date: Aug 2006
Location: Poland
Posts: 4,086
I don't know if the 600 lux is for the lamp with the concentrator on or off, but I agree there's a substantial difference in the brightness between the two configurations. I'd also add it's misfortunate in that you usually need the concentrator when the object is far away, but then the narrow spot is even more visible...
__________________
Sony PXW-FS7 | DaVinci Resolve Studio; Magix Vegas Pro; i7-5960X CPU; 64 GB RAM; 2x GTX 1080 8GB GPU; Decklink 4K Extreme 12G; 4x 3TB WD Black in RAID 0; 1TB M.2 NVMe cache drive
Piotr Wozniacki is offline   Reply With Quote
Old September 2nd, 2007, 10:18 AM   #30
Inner Circle

Join Date: Aug 2006
Location: Poland
Posts: 4,086
The various possible configurations of the HVL-LBP lamp are described in the interesting brochure here:

http://bssc.sel.sony.com/Broadcastan...broch_6-07.pdf

Looks like Khoi is right; engaging the concentrator can indeed output the 600 lux mentioned, while producing spot-light effect (see attached grab from the last wedding party I shot in a very dark room). On the other hand, using the diffuser flap will spread the light evenly, but will only output 300-400 lux (all measurements at 1 meter distance).

Edit: I forgot to mention the diffuser changes the light temperature from 5600K to 4400K, which can be noticed on the right grab - no spot, less bluish...
Attached Thumbnails
HVL-LBP lamp, and batteries-image20.jpg   HVL-LBP lamp, and batteries-image21.jpg

__________________
Sony PXW-FS7 | DaVinci Resolve Studio; Magix Vegas Pro; i7-5960X CPU; 64 GB RAM; 2x GTX 1080 8GB GPU; Decklink 4K Extreme 12G; 4x 3TB WD Black in RAID 0; 1TB M.2 NVMe cache drive

Last edited by Piotr Wozniacki; September 3rd, 2007 at 03:22 AM.
Piotr Wozniacki is offline   Reply
