Canon EOS R Full-Frame Mirrorless Camera at DVinfo.net

Brian Rhodes · September 5th, 2018, 04:25 AM

Canon EOS R Specs
Imaging
Lens Mount Canon RF
Camera Format Full-Frame
Pixels Actual: 31.7 Megapixel
Effective: 30.3 Megapixel
Max Resolution 6720 x 4480
Aspect Ratio 1:1, 3:2, 4:3, 16:9
Sensor Type / Size CMOS, 36 x 24 mm
File Formats Still Images: JPEG, RAW
Movies: MP4, MPEG-4 AVC/H.264
Audio: AAC, Linear PCM (Stereo)
Bit Depth 14-Bit
Dust Reduction System Yes
Memory Card Type SD
SDHC
SDXC
Image Stabilization Digital, 5-Way
AV Recording
Video Recording Yes, NTSC/PAL
Video Format 3840 x 2160p at 23.98/24/29.97 fps
1920 x 1080p at 23.98/24/29.97/59.94 fps
1280 x 720p at 29.97/59.94/120 fps
Aspect Ratio 16:9
Video Clip Length Up to 29 Min 59 Sec
Audio Recording Built-In Mic: With Video (Stereo)
Optional External Mic: With Video (Stereo)
Focus Control
Focus Type Auto & Manual Focus
Focus Mode Continuous-Servo AF (C), Manual Focus (M), Single-servo AF (S)
Autofocus Points Hybrid: 5655
Viewfinder/Display
Viewfinder Type Electronic
Viewfinder Size 0.5"
Viewfinder Pixel Count 3,690,000
Viewfinder Eye Point 23.00 mm
Viewfinder Coverage 100%
Viewfinder Magnification Approx. 0.71x
Diopter Adjustment -4 to +2 m
Display Screen 3.15" Rear Touchscreen Swivel LCD (2,100,000)
Screen Coverage 100%
Exposure Control
ISO Sensitivity Auto, 100-40000 (Extended Mode: 50-102400)
Shutter Type: Electronic & Mechanical
Speed: 30 - 1/8000 Second , Bulb Mode
Metering Method Center-Weighted Average Metering, Evaluative Metering, Partial Metering
Exposure Modes Modes: Aperture Priority, Bulb, Custom, Intelligent Auto, Manual, Programmed Auto, Shutter Priority
Metering Range: EV -3.0 - EV 20.0
Compensation: -3 EV to +3 EV (in 1/3 or 1/2 EV Steps)
White Balance Modes Auto, Cloudy, Color Temperature, Custom, Daylight, Flash, Fluorescent (White), Shade, Tungsten
Buffer/Continuous Shooting Up to 8 fps at 30.3 MP for up to 47 Frames in Raw Format
Up to 8 fps at 30.3 MP for up to 100 Frames in JPEG Format
Up to 3 fps at 30.3 MP for up to 47 Frames in Raw Format
Up to 3 fps at 30.3 MP for up to 100 Frames in JPEG Format
Up to 2.2 fps at 30.3 MP for up to 47 Frames in Raw Format
Up to 2.2 fps at 30.3 MP for up to 100 Frames in JPEG Format
Flash
Flash Modes Flash On
Slow Sync
Built-in Flash No
Max Sync Speed Not Specified by Manufacturer
Flash Compensation -3 EV to +3 EV (in 1/3 or 1/2 EV steps)
Dedicated Flash System eTTL
External Flash Connection Hot Shoe
Performance
Start-up Time 0.9 seconds
Shutter Lag 0.05 seconds
Self Timer 10 Seconds, 2 Seconds
Connectivity 1/8" Microphone, HDMI C (Mini), USB Type-C
Wi-Fi Capable Yes
Power
Battery 1 x LP-E6N Rechargeable Lithium-Ion Battery Pack, 7.2 VDC, 1865 mAh
AC Power Adapter Not Specified by Manufacturer
Operating/Storage Temperature Operating
32 to 104°F (0 to 40°C)
Humidity: 0 - 85%
Physical
Dimensions (W x H x D) 5.3 x 3.9 x 3.3" / 135.8 x 98.3 x 84.4 mm
Weight 1.45 lb / 660 g with battery and memory card

Chris Hurd · September 5th, 2018, 08:24 AM

Thanks, Brian...

See the full press releases here:

Canon Announces New Full-Frame Mirrorless EOS R System at DV Info Net

Canon Introduces Four Lenses in New RF Mount at DV Info Net

Cary Knoop · September 5th, 2018, 08:51 AM

Yet another photo camera doing a bit of video on the side.

I think a waste of money for those who use a camera primarily for video.

Chris Hurd · September 5th, 2018, 09:02 AM

Video specs:

4K 3840 x 2160: 29.97fps/24.00fps/23.98fps, ALL-I: 480Mbps, 3444 MB/min.
4K 3840 x 2160: 29.97fps/24.00fps/23.98fps, IPB: 120Mbps, 860 MB/min.

Full HD 1920 x 1080: 59.94fps*, ALL-I: 180Mbps, 1298 MB/min.
Full HD 1920 x 1080: 59.94fps*, IPB: 60Mbps, 431 MB/min.
Full HD 1920 x 1080: 29.97fps/24.00fps/23.98fps/HDR Video, ALL-I: 90Mbps, 654 MB/min.
Full HD 1920 x 1080: 29.97fps/24.00fps/23.98fps/HDR Video, IPB: 30Mbps, 216 MB/min.
Full HD 1920 x 1080: 29.97fps, IPB Light: 12Mbps, 87 MB/min.

HD 1280 x 720: 119.9fps, ALL-I: 160Mbps, 1144 MB/min.
HD 1280 x 720: 59.94fps, ALL-I: 80Mbps, 583 MB/min.
HD 1280 x 720: 59.94fps, IPB: 26Mbps, 187 MB/min.
HD 1280 x 720: 29.97fps/HDR Video, IPB: 13Mbps, 94 MB/min.

* Full HD 59.94 fps not available during EF-S cropped shooting.

Jack Zhang · September 5th, 2018, 08:34 PM

Once again, Nikon and Canon have overstepped Sony in offering 10bit 4:2:2 in their mirrorless offerings over HDMI out.

The A7SIII must be sweating bullets. Sony already confirmed no 10bit, so for those shooting in Log, Nikon and Canon are about to offer some really compelling offerings.

Edit: Uh... where's the headphone port? You know Vloggers want good audio... This might make the Nikon take an advantage over the Canon purely because there's a headphone port in case you're not using a Atomos recorder.

Other than that, looks like Canon does have the bitrate advantage, despite being 8bit internal.

Cary Knoop · September 5th, 2018, 08:55 PM

What's on Earth is the point of having a full frame camera for video if it can only produce 4K with a cropped sensor?

David Peterson · September 5th, 2018, 11:37 PM

Quote:

Originally Posted by Cary Knoop

What's on Earth is the point of having a full frame camera for video if it can only produce 4K with a cropped sensor?

Kills the point of having a selfie screen if the crop is so bad you can't have long enough arms to get yourself in frame!

Jack Zhang · September 6th, 2018, 05:25 PM

Holy crap. 1.8X crop may as well be Micro 4/3rds.

Yeah, avoid this camera. Get a Nikon Z6 for Full Frame, Nikon Z7 for S35 4K supersampled, and the Fujifilm X-T3 if you want APS-C 4K 60p 10bit 4:2:2 HDMI out.

David Peterson · September 7th, 2018, 08:26 AM

Or a GH5S for waveforms / timecode / full size HDMI / etc

Jack Zhang · September 7th, 2018, 08:54 AM

GH5s also has no recording time limit.

Panasonic must have something at CES to counter these offerings. Sony is better off delaying the A7SIII for it's own good.

David Peterson · September 10th, 2018, 09:23 PM

Canon has created a....GH4. Crop in 4K. Internal recording disabled when outputting 10bit.

How very 2014 of Canon!

Jack Zhang · September 11th, 2018, 09:40 AM

I'm genuinely interested to see the new Panasonic FF mirrorless and if it can offer no crop. It claims to offer no crop at DCI 4K 24p/25p, but I'll have to wait and see about the actual crop factors for UHD and HFR.

Peer Landa · September 14th, 2018, 02:34 AM

Quote:

Originally Posted by Jack Zhang

Holy crap. 1.8X crop may as well be Micro 4/3rds.

HA -- yea, come'on Canon, even my two-year old dinky 4/3rds f/1.7 Leica shoots 4k.

-- peer

Peer Landa · September 14th, 2018, 09:33 PM

Quote:

Originally Posted by Peer Landa

HA -- yea, come'on Canon, even my two-year old dinky 4/3rds f/1.7 Leica shoots 4k.

By the way, this is how my puny Leica looks nowadays (with follow-focus and lights):
